Quick Details
-
Warranty:
-
25 years
-
Brand Name:
-
Trina/Jinko/LONGi/JA or other
-
Model Number:
-
BEST second hand
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1772*1134*35mm
-
Product name:
-
300W mono perc half cell Solar Panels
-
Frame:
-
High Strength Alloy Steel Framed Module
-
Keyword:
-
Solar Panel 250 Watt
-
Weight:
-
23.5Kg
-
Cell:
-
Mono 166*166mm
-
Glass:
-
3.0mm Tempered Low Iron
-
Max system:
-
DC1500V (IEC)
-
Front/Back Side:
-
Max Staic Loading: 5400Pa/2400Pa
-
OEM Order:
-
Customized Solar Panel Aavilable
-
Application:
-
Solar Energy System
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial
-
Panel Efficiency:
-
20%
-
Warranty:
-
25 years
-
Brand Name:
-
Trina/Jinko/LONGi/JA or other
-
Model Number:
-
BEST second hand
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1772*1134*35mm
-
Product name:
-
300W mono perc half cell Solar Panels
-
Frame:
-
High Strength Alloy Steel Framed Module
-
Keyword:
-
Solar Panel 250 Watt
-
Weight:
-
23.5Kg
-
Cell:
-
Mono 166*166mm
-
Glass:
-
3.0mm Tempered Low Iron
-
Max system:
-
DC1500V (IEC)
-
Front/Back Side:
-
Max Staic Loading: 5400Pa/2400Pa
-
OEM Order:
-
Customized Solar Panel Aavilable
-
Application:
-
Solar Energy System
Product Description
|
Module number
|
250W solar panel
|
|
Solar cells efficiency
|
around 22%
|
|
Grade of solar cells
|
A grade
|
|
Dimensions(L*W*T) / Weight(kgs)
|
1722*1134*30/35mm/30kg
|
|
Solar cell / No. of cells and connections
|
monocrystalline silicon /
60-cell in series |
|
Front cover(material/thickness)
|
Low-iron tempered glass / 3.2mm
|
|
Encapsulation(material)
|
Ethylene Vinyl Acetate(EVA)
|
|
Frame(material/color)
|
Anodized aluminium alloy / Silver
|
|
Junction box protection degree
|
≥IP65
|
|
Cable /Cable connector Model
|
900mm solar cable with MC4 connectors
|
|
Standard Testing Conditions
|
Irradiance:1000W/m2,
Cell temperature:25ºC, AM:1.5(air mass). |
|
Max. static load, front(e. g.: snow/wind)
|
5400Pa
|
|
Max. static load, back(e. g.: wind)
|
2400Pa
|
|
Max. hailstone impact (diameter/velocity)
|
25mm; 23m/s
|
|
Max. system voltage (V)
|
1000V DC
|
|
Application Class
|
Class A
|
|
NOCT
|
45±2ºC
|
|
Operating temperature range
|
-40ºC- +85ºC
|
|
Power temperature coefficient
|
-0.45%/ºC
|
|
Current temperature coefficient
|
0.08%/ºC
|
|
Voltage temperature coefficient
|
-0.37%/ºC
|
|
Lifespan
|
≥25 years
|
|
Warranty
|
Power output warranty: 10 years over 90%,
25 years over 80%; |
|
Product Certifications / Standards
|
CE, IEC61215
|
|
Other Certifications
|
ISO9001:2008, RoHS
|
Strict QC System
Project
Product packaging
1. We usually use the carton for packing.
2. As customer requirements packing.
