Quick Details
-
Brand Name:
-
ROANPU
-
Model Number:
-
RAP-T1
-
Communication interface:
-
tcp/ip
-
Reader connectable:
-
2
-
card capacity:
-
20000
-
event record:
-
100000
-
Reader Interface:
-
Wiegand 26 / 34, Self-defined Wiegand Interface
-
Transmission Rate:
-
10/100Mbps self-adapting
-
Size of PCB board:
-
160mm *106mm
-
Extension Board:
-
Support (connect with a 4 group extension board)
-
Network Distance:
-
One bus<100m,connect with HUB to prolong
-
Data Save Mode:
-
FLASH, Power-down save 20 years
Quick Details
-
Special Features:
-
Other
-
Customized support:
-
Online technical support
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ROANPU
-
Model Number:
-
RAP-T1
-
Communication interface:
-
tcp/ip
-
Reader connectable:
-
2
-
card capacity:
-
20000
-
event record:
-
100000
-
Reader Interface:
-
Wiegand 26 / 34, Self-defined Wiegand Interface
-
Transmission Rate:
-
10/100Mbps self-adapting
-
Size of PCB board:
-
160mm *106mm
-
Extension Board:
-
Support (connect with a 4 group extension board)
-
Network Distance:
-
One bus<100m,connect with HUB to prolong
-
Data Save Mode:
-
FLASH, Power-down save 20 years
1.Parameters
|
Product Name |
TCP/IP 1 door access control |
|
Control Mode |
one door two way |
|
Processor |
ATMEGA64 |
|
Reader Interface |
Wiegand 26 / 34, Self-defined Wiegand Interface |
|
Reader Connectable |
2or4pcs |
|
Card Capacity |
20000pcs |
|
Event Record |
100000pcs |
|
Alarm Record |
20000pcs |
|
Exit Button Connectable |
1pcs |
|
Output Electric Lock |
2 groups |
|
Input Port |
1 reader |
|
Output Port |
2 + extension board |
|
Extension Board |
Support (connect with a 4 group extension board) |
|
Communication Interface |
TCP/IP |
|
Transmission Rate |
10/100Mbps self-adapting |
|
Network Distance |
One bus<100m,connect with HUB to prolong |
|
Working Voltage |
9-15V DC |
|
Working Temperature |
-10- +55°C |
|
Working Humidity |
10%-90% |
|
Anti-static Interference |
≥15KV |
|
Data Save Mode |
FLASH, Power-down save 20 years |
|
Size of PCB board
|
160mm *106mm
|
|
Area of Application |
Storage and operation hall of banking system |
|
Places with high security demand |
|
|
Storage for confidential documents, papers and valuable items |
|
|
Warehouses for storing inflammable, explosive, poisonous, toxic, radioactive materials |
|
|
Museum, antique stores and places for displaying or storing important and valuable articles and treasures |
|
|
Governmental offices, R&D institutes, business buildings and factories |
|
|
Intelligent buildings, intelligent residential areas |
|
|
Prison, detention house |
|
|
Controller centers for public facilities and airports |
2.Features&Function
The user-friendly Access software programs the system within a few minutes, from a non-dedicated PC. Access Software provides numerous access control and alarm monitoring features: expiry date for clubs, automatic activation, interlock between two doors, time zones, supervision, anti-passback, activity reports.Each alarm input is programmable: operating mode (NO or NC), time zones, local reflex Specific alarms are triggered according to the number of unsuccessful attempts, the time limit for door closing (door alarm), the duress code.Whenever required, the data stored in the controllers is transferred to the computer and activity reports are printed. Each controller works independently and keeps its own database. In case of power cut, the back-up battery (up to 12V- 17 A/h) ensures numerous hours of full autonomy. Visual LEDS indicate the inputs, outputs and communication statu
3.Our service
1.Professional staff answer your questions in English.
2.Customized design and OEM
3. supported by our professional engineers.
4.Special discount of our distributors or agents in their area.
5.Packing in standard export carton, suggest you pack it by wooden case to protect the products.
