- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 Years Warranty
-
Brand Name:
-
DAH
-
Model Number:
-
DHM-60X10/FS
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1903*1134*32mm
-
Product name:
-
hi power solar panel 450 watt 450w solar pv panels free shipping
-
Connector:
-
MC4 Compatible
-
Junction box:
-
IP68, 3 Bypass Diodes
-
Glass:
-
3.2mm High Transmission, Antireflection Coating
-
Cable:
-
4.0mm2, 300/400mm in length
-
Maximum system voltage:
-
1500V DC
-
Operating Temperature:
-
-40 ~ +85°C
-
Maximum series fuse rating:
-
25A
-
Application level:
-
Class A
-
Nominal operating cell temperature:
-
45°C±2°C
-
Certificate:
-
IEC 61215/IEC 61730/CE/FIDE/INMETRO
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, All Black
-
Panel Efficiency:
-
21.78%
-
Warranty:
-
25 Years Warranty
-
Brand Name:
-
DAH
-
Model Number:
-
DHM-60X10/FS
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1903*1134*32mm
-
Product name:
-
hi power solar panel 450 watt 450w solar pv panels free shipping
-
Connector:
-
MC4 Compatible
-
Junction box:
-
IP68, 3 Bypass Diodes
-
Glass:
-
3.2mm High Transmission, Antireflection Coating
-
Cable:
-
4.0mm2, 300/400mm in length
-
Maximum system voltage:
-
1500V DC
-
Operating Temperature:
-
-40 ~ +85°C
-
Maximum series fuse rating:
-
25A
-
Application level:
-
Class A
-
Nominal operating cell temperature:
-
45°C±2°C
-
Certificate:
-
IEC 61215/IEC 61730/CE/FIDE/INMETRO
Solar Panel Details
|
Maximum Power (Pmax)
|
450W
|
455W
|
460
W
|
465W
|
470W
|
||||
|
Open-circuit Voltage (Voc)
|
41.6V
|
41.8
V
|
42
V
|
42.2V
|
42.4V
|
||||
|
Maximum Power Voltage (Vmp)
|
35.2
|
35.4
A
|
35.6
|
35.8
|
36
|
||||
|
Short-circuit Current (Isc)
|
13.66A
|
13.72A
|
13.78A
|
13.84A
|
13.9A
|
||||
|
Maximum Power Current (Imp)
|
12.78A
|
12.85A
|
12.92A
|
12.99A
|
13.06A
|
||||
|
Module Efficiency
|
20.85%
|
21.08%
|
21.32%
|
21.55
%
|
21.78
%
|
||||
|
Power Tolerance
|
0~+5W
|
|
|
|
|
||||
|
Standard Test Environment
|
Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5
|
|
|
|
|
||||
FAQ
Q1:How does DAH Solar Full-Screen Module increase power generation by 6-15%?
A1:For regular module, the dust and rainy water will deposit at the bottom of the frame,which will have a big influence on power generation.Full-Screen Module front side(A side) is frameless , so no water and dust will stop on the surface
Q2:Compared with regular PV module, is there any difference in the installation?
A2:No difference, use the same material.
Q3:How does snow infect the power generation?
A3:With the frame of the regular module, the snow blocks the surface, and result in the reduction of power generation,Full-Screen Module can solve this problem effectively.
Q4:Does the Full-Screen Module as reliable as the regular PV module?
A4:According to the strict TÜV lab test, the Full-Screen Module performed excellently under harsh environments. The Full-Screen Module showed waterproof (IP68) and pressure resistance (Front-side 5400Pa, Back-side 2400Pa)
