1. Glass greenhouse has a good light transmittance, single-layer float glass, the transmittance of more than 90%, double layers hollow glass transmittance of more than 80%;
2. Light transmittance stable, no water vapor entering, anti aging;
3. anti-dew;
4. Large area of greenhouse lighting, indoor light uniform;
5. The interior is spacious and bright, and the operating space is big, and the utilization rate of the greenhouse is high;
6. Looks beautiful, and has a strong ornamental;
7. Greenhouse drainage capacity is very strong, and it can be a large area of multi-span.
- Product Details
- {{item.text}}
Quick Details
-
Instruction for use:
-
customized
-
Model Number:
-
GG-Commercial Glass Greenhouse
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HUALIANG
-
Length:
-
10-100m
-
Width:
-
10-200m
-
Span Width:
-
8m 9.6m 12m
-
Bay width:
-
4m
-
Roof cover:
-
Single fiber glass or PC sheet or Film
-
Side cover:
-
Hollow glass 4/5+8/9+4/5mm
-
Cooling system:
-
Cooling fan and cooling pad
-
Ventilation system:
-
Roof window and side window
Quick Details
-
Size:
-
Large
-
Type:
-
Multi-Span Agricultural Greenhouses
-
Manufacturer:
-
HUALIANG
-
Instruction for use:
-
customized
-
Model Number:
-
GG-Commercial Glass Greenhouse
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HUALIANG
-
Length:
-
10-100m
-
Width:
-
10-200m
-
Span Width:
-
8m 9.6m 12m
-
Bay width:
-
4m
-
Roof cover:
-
Single fiber glass or PC sheet or Film
-
Side cover:
-
Hollow glass 4/5+8/9+4/5mm
-
Cooling system:
-
Cooling fan and cooling pad
-
Ventilation system:
-
Roof window and side window
Product Description
Characteristics Of Glass Greenhouse
Greenhouse Abstract
A greenhouse (also called a glasshouse, or, if with sufficient heating, a hothouse) is a structure with walls and roof made chiefly of transparent material, such as glass, in which plants requiring regulated climatic conditions are grown. These structures range in size from small sheds to industrial-sized buildings. A miniature greenhouse is known as a cold frame. The interior of a greenhouse exposed to sunlight becomes significantly warmer than the external ambient temperature, protecting its contents in cold weather.
Many commercial glass greenhouses or hothouses are high tech production facilities for vegetables or flowers. The glass greenhouses are filled with equipment including screening installations, heating, cooling, lighting, and may be controlled by a computer to optimize conditions for plant growth.
Glass Greenhouse Abstract
Glass greenhouse is a type of greenhouse covered by glass as lighting materials, which belongs to a kind of greenhouse and in cultivation facility, the glass greenhouse has the longest life, which is suitable for use in a variety of areas, and all kinds of climate conditions. In the greenhouse industry, according to the size of the span and width, it is divided into many construction types, and with different using ways, it is divided into: vegetables glass greenhouse, flowers glass greenhouse, seedling greenhouse glass, glass ecological greenhouse, research glass greenhouse, three-dimensional glass greenhouse, special-shaped glass greenhouse, sightseeing glass greenhouse, intelligent glass greenhouse and so on. Greenhouse owners are free to deploy in the area and the way of use. The minimum one is garden greenhouse and the maximum one has the height of up to 10 meters, span of up to 16 meters, width up to 10 meters, and the intelligent degree may achieve a key control. The winter heating system of glass greenhouse can be used in many ways.
Glass Greenhouse Application
1. planting vegetable, for example, tomato, cucumber, peper, chilli, leaf vegetable, etc.
2. planting flower.
3. planting fruits.
4. soilless culture.
5. agriculture trial.
6. as restaurant
7. for sightseeing
Characteristic&Parameters
|
Type
|
Multi-Span Glass Greenhouse
|
|
Span Width
|
8m/9.6m/10.8m/12m
|
|
Bay width
|
4m /8m
|
|
Gutter hight
|
3-8m
|
|
Snow load
|
0.5KN/M
2
|
|
Wind load
|
0.6KN/M
2
|
|
Hanging load
|
15KG/M
2
|
Details Images
Greenhouse steel structure
270 um.
Cover Materials
The glass has a good light transmittance,double layer glass has more than 80% transmittance,anti dew,anti uv
Outer Sunshade System
This system also has hail protection. Button control switch, reduce the internal temperature and avoid damages to plants caused by
intense sunlight.
intense sunlight.
Cooling System
Internal Curtain System
Inner Sunshade System
Seedbed,nursery bed
Seedbed is also called nursery bed, nursery bench, seedling bed, etc.
The seedbed application is:
1. planting flowers
2. germinating grow
3. planting vegetable
4. hydroponics
The seedbed application is:
1. planting flowers
2. germinating grow
3. planting vegetable
4. hydroponics
Heating System
Boiler equipment includes boiler body, chimney, computer control box, maintenance-free water pump, soot processor, water collector, water separator, check valve, opening and closing valves, pipes, pipe valves, instruments .
Electric Control System
Greenhouse control system is greenhouse composed of control cabinet, sensors and circuits. It can realize the automatically
control
of water heaters and cooling system to save energy.
NFT hydroponic
DWC Hydroponic
Dutch Bucket Culture
Aeroponic Cultivation System
Rock Wool Substrate Culture
Aquaponics Culture
