- Product Details
- {{item.text}}
Quick Details
-
Production Capacity:
-
High
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
WANLONG
-
Voltage:
-
380V/50Hz
-
Dimension(L*W*H):
-
6000*55000*3360
-
Weight:
-
7500 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Lifting System:
-
Hydraulic
-
Max.cutting size:::
-
3200*2000*230
Quick Details
-
Type:
-
Bridge Saw
-
Power:
-
18.5kw
-
Cutting thickness (max):
-
Other
-
Production Capacity:
-
High
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
WANLONG
-
Voltage:
-
380V/50Hz
-
Dimension(L*W*H):
-
6000*55000*3360
-
Weight:
-
7500 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Lifting System:
-
Hydraulic
-
Max.cutting size:::
-
3200*2000*230
Product Introduction & Parameter
|
Technical Parameters |
||
|
Model |
PLC-700 |
|
|
Max.diameter of blade |
mm |
700 |
|
Main motor power |
KW |
18.5 |
|
Blade rotation degree |
n° |
0-45° |
|
Table dimensions(L*W) |
mm |
3200*2000 |
|
Table tilting degree |
n° |
0-85° |
|
Table rotating degree |
n° |
90°/360° |
|
Max. cutting size(L*W*H) |
mm |
3200*2000*230 |
|
Overall dimensions(L*W*H) |
mm |
6000*5500*3360 |
|
Water consumption |
m³ |
4 |
|
Approximate weight |
kg |
6400 |
2
3 years of experience in diamond tools industry;
900 experienced employees;
2100 clients from 108 countries and regions;
200,000 pieces segments of daily production output.
Wanlong is now one of the biggest manufacturers of diamond tools, supplying products for stone cutting, polishing, grinding and drilling.
Following products are supplie
d:
1. Diamond segments and diamond saw blade, ranging from 200mm to 3500mm .
2. Dry cutting & turbo saw blade.
3. Diamond wire and beads for granite & marble.
4. Polishing abrasive.
5. PDC Cutters for Oil & Gas Drill Bits and Chain Saw machine.
6. Bridge Cutting Machine & Auto Polishing Machine, etc.
2). QZQ-900/1200 Bridge Cutting Machine
3).PLC-400/600 Laser Bridge Cutting Machine
4).MS-2600/3000 Polishing Machine
5).SY-S80 Hydraulic Pressing Machine, etc.
If any product meet your demand, please contact us for further information.
If any request, just feel free to contact us, we will keep providing quality products and excellent sevice for you.
