Quick Details
-
Name:
-
Paints Gloss Meter Colour screen 60
Quick Details
-
Warranty:
-
12 months, 1 Year
-
Place of Origin:
-
China
-
Brand Name:
-
ETERNAL
-
Name:
-
Paints Gloss Meter Colour screen 60
Product Description
Paints Gloss Meter Colour screen 60
Description:
This instrument is a glossiness meter independently developed by the company with independent intellectual property rights. It is a glossiness measuring instrument designed and manufactured with reference to the international standard iso2813 and the Chinese national standard GB / t9754. It is a glossmeter with a 3.5-inch large screen display, which is easy to use, stable in performance and accurate in measurement.
Features:
(1) 3.5-inch large color screen, high resolution (480 * 320) full view display;
(2) Conform to standards iso2813, GB / t9754, astmd523 and astmd2457;
(3) Simple and atmospheric appearance design and ergonomic structure design;
(4) Flexible selection of automatic calibration after startup, simple and convenient operation;
(5) Multiple groups of measurement data are displayed at the same time for comparison;
(6) High hardware configuration, incorporating a number of innovative technologies;
(7) Built in rechargeable battery, saving and environmental protection;
(8) Automatic shutdown function, saving power.
Specification
|
l Product model: hg60s
|
|
l Measuring angle: 60 °
|
|
l Measuring spot (mm) 9x15
|
|
l Measuring range: 0 ~ 200gu
|
|
l Division value 1gu
|
|
l Measurement repetition accuracy 0 ~ 100gu: 1gu;
|
|
l 100~200GU:1%GU
|
|
l The measurement accuracy meets the requirements of JJG 698 secondary working glossmeter
|
|
l Chromaticity response CIE 1931 (2 °) photometric response under CIE C light source
|
|
l Measurement time: 0.5s
|
|
l Size 160 × 75 × 90mm (L × wide × High)
|
|
l Weight: About 350g
|
|
l Language: Simplified Chinese and English
|
|
l Battery capacity 3200mah lithium battery, more than 5000 times in 8 hours
|
|
l Display TFT true color 3.5inch, resolution 320 * 480
|
|
l Interface: USB / RS-232
|
|
l Store data
|
|
l Upper computer software
|
|
l Operating temperature range: 0 ~ 40 ℃ (32 ~ 104 ° f)
|
|
l Storage temperature range: - 20 ~ 50 ℃ (- 4 ~ 122 ° f)
|
|
l Humidity less than 85%, no condensation
|
|
l Standard accessories: power adapter, data cable, manual, wiping cloth, calibration standard board
|
|
l Optional accessories: micro printer
|
|
l Note: the technical parameters are for reference only, subject to the products actually sold
|
