Quick Details
-
Brand Name:
-
Bedford
-
Dimension(L*W*H):
-
300*300*385mm
-
Capacity:
-
18L
-
Weight:
-
3.59KG
-
Inner Material:
-
Virgin polypropylene liner
-
Outer Material:
-
Two part polyurethane, epoxy primed paint finish
-
Working Temperature(℃):
-
10 - 90 ℃
-
Product name:
-
Pressure tank
-
Feature 1:
-
single diaphragm design
-
Feature 2:
-
nature polypropylene liner
-
Feature 3:
-
fully test
-
Feature 4:
-
maintenance free
-
Feature 5:
-
Aritight O-ring sealed bonnet
Quick Details
-
Volume (m³):
-
0.018m³
-
Max Working Pressure(MPa):
-
10 MPa
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Bedford
-
Dimension(L*W*H):
-
300*300*385mm
-
Capacity:
-
18L
-
Weight:
-
3.59KG
-
Inner Material:
-
Virgin polypropylene liner
-
Outer Material:
-
Two part polyurethane, epoxy primed paint finish
-
Working Temperature(℃):
-
10 - 90 ℃
-
Product name:
-
Pressure tank
-
Feature 1:
-
single diaphragm design
-
Feature 2:
-
nature polypropylene liner
-
Feature 3:
-
fully test
-
Feature 4:
-
maintenance free
-
Feature 5:
-
Aritight O-ring sealed bonnet
SIngle diaphragm design Vertical Stainless Steel Pressure Tank Expansion Tank Pressure Vessel Tank
The pressure tank is used in the closed water circulation system to balance the water volume and pressure, avoiding frequent opening of the safety valve and frequent replenishment of the automatic water replenishment valve.
| Model | CNNECTION THREAD | Pressure TANK INFLATABLE VALUE(Bar) | MAXIMUM WORKING PRESSURE(bar) | MAXIMUM WORKING TEMPERATURE(℃) | VOLUM(L) |
| B55-PTV04-010 | G1* | 1.9 | 10 | 90 | 4 |
| B55-PTV08-010 | G1* | 1.9 | 10 | 90 | 8 |
| B55-PTV18-010 | G1* | 1.9 | 10 | 90 | 18 |
Click to view more parameter information
Product advantages:
1.Efficient and safe storage, stable air pressure and no air leakage.
2.High-precision sealing, seamless welding, no air leakage, efficient storage.
Features:
1.Stable water pressure
2.Buffer constant pressure effect is good
3.Variety of specifications
