Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
Shinjuess
-
Model Number:
-
SJF2016
-
Place of Origin:
-
China
-
Horsepower:
-
3-7.5
-
Power:
-
2.2-5.5kw
-
Flow rate:
-
21L/min (5.5GPM)
-
Speed:
-
1450rpm
-
Shaft:
-
Hollow 28mm
-
Certification:
-
CE
Quick Details
-
Application:
-
Commercial Buildings, Family Homes, Irrigation and Agriculture, Washing and Cleaning
-
Pressure:
-
10-150bar
-
Voltage:
-
220v,380v
-
Warranty:
-
1 year
-
Brand Name:
-
Shinjuess
-
Model Number:
-
SJF2016
-
Place of Origin:
-
China
-
Horsepower:
-
3-7.5
-
Power:
-
2.2-5.5kw
-
Flow rate:
-
21L/min (5.5GPM)
-
Speed:
-
1450rpm
-
Shaft:
-
Hollow 28mm
-
Certification:
-
CE
Products Description
Parameters
|
Item
|
Flow
|
|
Pressure
|
|
Powe
|
|
Speed
|
Packing Size
|
G.W.
|
|||
|
|
L/min
|
gpm
|
bar
|
psi
|
hp
|
kw
|
rpm
|
cm
|
kg
|
|||
|
SJF1810
|
11
|
2.9
|
250
|
3625
|
7.3
|
5.5
|
1450
|
30*28*23
|
10
|
|||
|
SJF1812
|
13
|
3.4
|
250
|
3625
|
8.5
|
6.4
|
1450
|
30*28*23
|
10
|
|||
|
SJF1814
|
15
|
4.0
|
250
|
3625
|
10
|
7.5
|
1450
|
30*28*23
|
10
|
|||
|
SJF2014
|
19
|
5
|
180
|
2610
|
8.9
|
6.7
|
1450
|
30*28*23
|
10
|
|||
|
SJF2016
|
21
|
5.6
|
180
|
2610
|
10
|
7.5
|
1450
|
30*28*23
|
10
|
|||
Details Images
1. CYLINDER
Type 59-1 Brass forged.
2. CRANKCASE
Die-cast ADC-12 national standard aluminum alloy, anodized, classic look.
3. CONNECTING ROD
Integrated zinc alloy.
4. Precision machined BALL BEARINGS and NEEDLE BEARINGS, nitriding treatment, Increase toughness, wear resistance, hardness and strength.
5. PLUNGER solid stainless steel . ceramic coating , precision grinded./
Precision machining hard solid CERAMIC PLUNGER for greater durability.
6. SEAL ASSEMBLY
High and low pressure double water seal design, the main water seal is fabric material, U-shape, the oil seal is made of Buna-N material, which is friction resistant, corrosion resistant and oil resistant.
7. CRANKSHAFT
forged steel alloy, precise handling ensures durability and service life.
8. Stainless steel CHECK VALVE, durable, long service life, easy disassembly and easy maintenance.
Type 59-1 Brass forged.
2. CRANKCASE
Die-cast ADC-12 national standard aluminum alloy, anodized, classic look.
3. CONNECTING ROD
Integrated zinc alloy.
4. Precision machined BALL BEARINGS and NEEDLE BEARINGS, nitriding treatment, Increase toughness, wear resistance, hardness and strength.
5. PLUNGER solid stainless steel . ceramic coating , precision grinded./
Precision machining hard solid CERAMIC PLUNGER for greater durability.
6. SEAL ASSEMBLY
High and low pressure double water seal design, the main water seal is fabric material, U-shape, the oil seal is made of Buna-N material, which is friction resistant, corrosion resistant and oil resistant.
7. CRANKSHAFT
forged steel alloy, precise handling ensures durability and service life.
8. Stainless steel CHECK VALVE, durable, long service life, easy disassembly and easy maintenance.
