Quick Details
-
Temperature compensation principle:
-
Reference gas measurement
-
Measuring range:
-
0~1.0MPa(abs.) or -0.1~0.9MPa
-
Acuracy(@ 20°C):
-
± 1 %
-
shock:
-
40g/ 11ms
-
Contact type:
-
Microswitch
-
Sealing performance:
-
≤1*10^(-8) mbar l/s(with Helium gas)
-
Number of contacts:
-
Up to 4 pairs
-
Contact resistance:
-
≤1Ω
-
Insulation strength:
-
2kV, 1min
-
Nominal size:
-
100mm
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
ROYE
-
Model Number:
-
RDM
-
Temperature compensation principle:
-
Reference gas measurement
-
Measuring range:
-
0~1.0MPa(abs.) or -0.1~0.9MPa
-
Acuracy(@ 20°C):
-
± 1 %
-
shock:
-
40g/ 11ms
-
Contact type:
-
Microswitch
-
Sealing performance:
-
≤1*10^(-8) mbar l/s(with Helium gas)
-
Number of contacts:
-
Up to 4 pairs
-
Contact resistance:
-
≤1Ω
-
Insulation strength:
-
2kV, 1min
-
Nominal size:
-
100mm
Product Description
| Temperature compensation principle | Reference gas measurement |
| Measuring range | 0~1.0MPa(abs.) or -0.1~0.9MPa |
| Acuracy(@ 20°C) | ± 1 % |
| shock | 40g/ 11ms |
| Contact type | Microswitch |
| Contact resistance | ≤1ΩW |
| Insulation strength | 2kV, 1min |
| Resistance of insulation | > 20 MΩ |
| Sealing performance | ≤1×10 -8 mbar·l/s(with Helium gas) |
| Operating ambient | T:-40~+ 80 ℃ , ≤ 95% RH |
| Ingress protection | IP65 |
| Number of contacts | Up to 4 pairs |
| Nominal size | 100mm |
| Pressure range for sensor | 0~1.0MPa (abs.) |
| Accuracy of pressure for sensor | ±0.5%F.S |
| Accuracy of temp. for sensor | ±1℃ |
| Density range for sensor | 0~1.0MPa(abs.) |
| Accuracy of density for sensor | ±1%F.S. |
| Communication mode for sensor | RS485 |
| Communication protocol for sensor | Modbus RTU |
| Electromagnetic Compatibility for sensor |
IEC 61000-4-2 3A
IEC 61000-4-3 3A IEC 61000-4-4 3A IEC 61000-4-5 4A IEC 61000-4-6 3A IEC 61000-4-8 5A IEC 61000-4-9 5A IEC 61000-4-10 4A |
| Supply voltage for sensor | DC 24V±10% |
| Rated power for sensor | ≤1W |
| Certification | CE |
| Place of Origin | China |
