Quick Details
-
Color:
-
Full color
-
Panel Size:
-
320*160MM
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P2.5
-
Panel Dimension:
-
320mm(W) * 160mm(H)
-
Pixel pitch:
-
2.5mm
-
Pixel Density:
-
160000 dot/m2
-
Pixel configuration:
-
1R1G1B
-
Pixel resolution:
-
128 dot * 64 dot
-
Driving IC:
-
ICN 2037 / 2153
-
Scan Rate:
-
1/32S
-
Refresh frepuency:
-
1920-3300 HZ/S
-
Brightness:
-
800-1000 cd/m2
-
IP protective index:
-
IP43
-
Pixel Pitch:
-
2.5MM
Quick Details
-
Application:
-
indoor
-
Type:
-
LED
-
Brand Name:
-
Brighter
-
Color:
-
Full color
-
Panel Size:
-
320*160MM
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P2.5
-
Panel Dimension:
-
320mm(W) * 160mm(H)
-
Pixel pitch:
-
2.5mm
-
Pixel Density:
-
160000 dot/m2
-
Pixel configuration:
-
1R1G1B
-
Pixel resolution:
-
128 dot * 64 dot
-
Driving IC:
-
ICN 2037 / 2153
-
Scan Rate:
-
1/32S
-
Refresh frepuency:
-
1920-3300 HZ/S
-
Brightness:
-
800-1000 cd/m2
-
IP protective index:
-
IP43
-
Pixel Pitch:
-
2.5MM
Product Details
|
Item
|
|
|
Indoor P2.5
|
Indoor P4
|
Indoor P5
|
||
|
Module
|
|
Panel Dimension
|
320mm(W) * 160mm(H)
|
320mm(W) * 160mm(H)
|
320mm(W) * 160mm(H)
|
||
|
|
|
Pixel pitch
|
2.5mm
|
4mm
|
5mm
|
||
|
|
|
Pixel Density
|
160000 dot/m2
|
62500 dot/m2
|
40000 dot/m2
|
||
|
|
|
Pixel configuration
|
1R1G1B
|
1R1G1B
|
1R1G1B
|
||
|
|
|
LED specification
|
SMD2121
|
SMD2121
|
SMD3528 / 2121
|
||
|
|
|
Pixel resolution
|
128 dot * 64 dot
|
80 dot * 40 dot
|
64 dot * 32 dot
|
||
|
|
|
Average power
|
30W
|
26W
|
15W/24W
|
||
|
|
|
Panel weight
|
0.39KG
|
0.3KG
|
0.33KG
|
||
|
Cabinet
|
|
Cabinet size
|
640mm*640mm*85mm
|
960mm*960mm*85mm
|
640mm*640mm*85mm,
960mm*960mm*85mm
|
||
|
|
|
Cabinet Resolution
|
256 dot * 256 dt
|
240 dot * 240 dot
|
128 dot * 128 dot, 192 dot*192 dot
|
||
|
|
|
Quantity of panel
|
8pcs
|
18pcs
|
8pcs, 18pcs
|
||
|
|
|
Hub connecting
|
HUB75-E
|
HUB75-E
|
HUB75-E
|
||
|
|
|
Best viewing angle
|
140/120
|
140/120
|
140/120
|
||
|
|
|
Best viewing distance
|
2-30M
|
4-30M
|
5-30M
|
||
|
|
|
Operating temperature
|
-10C°~45C°
|
-10C°~45C°
|
-10C°~45C°
|
||
|
|
|
Screen power supply
|
AC110V/220V - 5V60A
|
AC110V/220V - 5V60A
|
AC110V/220V - 5V60A
|
||
|
|
|
Max power
|
780 W/m2
|
700 W/m2
|
750W/m2
|
||
|
|
|
Average power
|
390 W/m2
|
350 W/m2
|
375W/m2
|
||
|
Technical
Signal Index
|
|
Driving IC
|
ICN 2037 / 2153
|
ICN 2037 / 2153
|
ICN 2037 / 2153
|
||
|
|
|
Scan Rate
|
1/32S
|
1/20S
|
1/16S
|
||
|
|
|
Refresh frepuency
|
1920-3300 HZ/S
|
1920-3840 HZ/S
|
1920-3840 HZ/S
|
||
|
|
|
Display color
|
4096*4096*4096
|
4096*4096*4096
|
4096*4096*4096
|
||
|
|
|
Brightness
|
800-1000 cd/m2
|
800-1000 cd/m2
|
900-1100 cd/m2
|
||
|
|
|
Life span
|
100000Hours
|
100000Hours
|
100000Hours
|
||
|
|
|
Control distance
|
<100M
|
<100M
|
<100M
|
||
|
|
|
Operating Humidity
|
10-90%
|
10-90%
|
10-90%
|
||
|
|
|
IP protective index
|
IP43
|
IP43
|
IP43
|
||
