uht milk production plant /line uht milk machine/small scale uht milk processing plant

uht milk production plant /line uht milk machine/small scale uht milk processing plant

FOB Reference Price: Get Latest Price

≥1 Pieces

US $20888

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Power:: 10kw

Weight:: 2500 KG

Product name:: small scale uht milk processing plant

Usage:: dairy milk processing line

Capacity:: 500lph

Material:: SUS316L

PHE heat exchange:: To cool and heat milk

Homogenizer:: 25Mpa

After-sales Service Provided:: Service Machinery Overseas

Tank type:: 300L/500L/1000L

Quick Details

Place of Origin:: Jiangsu, China

Brand Name:: QJ

Voltage:: 380v

Power:: 10kw

Weight:: 2500 KG

Product name:: small scale uht milk processing plant

Usage:: dairy milk processing line

Capacity:: 500lph

Material:: SUS316L

PHE heat exchange:: To cool and heat milk

Homogenizer:: 25Mpa

After-sales Service Provided:: Service Machinery Overseas

Tank type:: 300L/500L/1000L

Product Overview

UHT Milk Process Plant

YGT milk production plants include a range of milk processing equipment to perform heat exchange, sterilizer, homogenizer and some others. to make the variety of milk products like UHT milk, cheese, butter, cream, skimmed milk, toned milk or much more.

YGT milk plants could design by the fluid milk production(UHT milk), cheese production , ice cream production.

YGT Composed by below part :

-- Milk Tank: The milk tanks are the prime components in any milk processing plants that used to store raw milk, skimmed milk, favor milk or cream.
-- UHT Sterilizer: the process of heat treatment to reduce enzymatic activity and kill pathogenic bacteria. The main purpose of ygt pasteurization in dairy plants is to make the product safe for use and to extend product shelf life.
-- Homogenizer: improves the texture, taste and viscosity of cream or milk-based drink and prevents sedimentation in the dairy products.

-- Filling system: by aseptic filler to guarantee the clean air circulation and match aseptic package, to prolong the shelf time. with optional by Tetra pak box (200-1000ml), PrePak bag (100-1000ml), Flexible BIB bag (2-220L).

FEATURES AT A GLANCE

1. MILK COLLECTION SYSTEM

2. MILK STANDARD SYSTEM

3. MILK UHT STERILIZER

4. ASEPTIC FILLER

YGT plant could flexible for UHT milk, pasteurizer, yoghurt, cream etc dairy product, capacity range from 500l/h-10,000L/h as per site need.

ASEPTIC FILLER

MILK STERILIZER

HOMOGENIZER

PRODUCT SPECIFICATIONS

No	Equipment list	Data	Qty	Specification
1	Plate heat exchange	SUS304	1	To fast cool milk after collection
2	Standard Tank	3000L	2	to blend the milk with sugar if need by technology
3	Pipe filter	SUS304	2	100mesh, to remove particle from milk
4	Pump	1.5kw	2	centrifugal structure, to transfer milk to next
5	Degassor	2.2kw	1	by vacuum, to remove the air and smell from milk
6	Homogenizer	15kw	1	by high pressure process, to prevent milk separation
7	UHT sterilizer	8.5kw	1	by high temperature, short time to sterilize milk
8	Aseptic Filling machine	10kw	1	to sterilize milk into pouch/carton box for long storage
