Quick Details
-
Network:
-
RS485
-
Response time:
-
≤8S
-
Monitoring distance:
-
1500M
-
Operating temperature:
-
-10℃~60℃
-
Operating humidity:
-
5%~95%RH (no condensing)
-
Power comsumption:
-
<2W
-
Dimension (L*W*H):
-
70mm*58.7*85.8mm
-
Warranty:
-
12 months
-
Customized support:
-
OEM
-
Certification:
-
ISO, CE
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
NONE
-
Model Number:
-
SPD-780B
-
Network:
-
RS485
-
Response time:
-
≤8S
-
Monitoring distance:
-
1500M
-
Operating temperature:
-
-10℃~60℃
-
Operating humidity:
-
5%~95%RH (no condensing)
-
Power comsumption:
-
<2W
-
Dimension (L*W*H):
-
70mm*58.7*85.8mm
-
Warranty:
-
12 months
-
Customized support:
-
OEM
-
Certification:
-
ISO, CE
Products Description
Product Paramenters
|
Model number
|
SPD-780B
|
|
Response time
|
≤8S
|
|
Monitoring distance
|
1200M
|
|
Operating temperature
|
-10℃~60℃
|
|
Operating humidity
|
5%~95%RH (no condensing)
|
|
Power supply
|
AC: 24V / 220V; DC: 12V / 24V optional
|
|
Power consumption
|
<2W
|
|
Communication
|
RS485
|
|
Support protocol
|
MODBUS-RTU， MODBUS-A S C I I
|
|
Baud rate
|
Defaulted as 9600 bit/s; 2400, 4800, 19200 bit/s can be selected
|
|
Data format
|
N,8,1
|
|
Address setting
|
Defaulted as 199; 1 to 254 can be selected
|
|
Relay
|
Normally open or normally closed
|
|
Dimension (L*W*H)
|
85.8*72.0*58.7mm
|
|
Installation
|
DIN-rail mount
|
