Quick Details
-
Conveyor Load:
-
170 kg
-
Conveyor speed:
-
0.22 m/s
-
Penetration:
-
33~40 mm steel
-
Resolution:
-
38~40 AWG
-
Film safety:
-
Guarantee ISO 1600 Film
-
X-ray leakage:
-
<0.5 μSv/h
-
Anode voltage:
-
140~160 kV
-
Beam direction:
-
80°
-
X-ray converter:
-
L-Shaped Photodiode Array
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Fangjiwuxian
-
Tunnel Size:
-
650 x 500 mm
-
Conveyor Load:
-
170 kg
-
Conveyor speed:
-
0.22 m/s
-
Penetration:
-
33~40 mm steel
-
Resolution:
-
38~40 AWG
-
Film safety:
-
Guarantee ISO 1600 Film
-
X-ray leakage:
-
<0.5 μSv/h
-
Anode voltage:
-
140~160 kV
-
Beam direction:
-
80°
-
X-ray converter:
-
L-Shaped Photodiode Array
X Ray Baggage Scanner Paramenters
|
Basic parameters
|
|
Operating environment
|
|
||
|
The tunnel size
|
650(W)*500(H)mm
|
Operating temperature/humidity
|
0℃ ~ 45℃/ 20% ~ 95% (non-condensing)
|
||
|
Conveyor Max Load(kgs)
|
50kg
|
Storage temperature/humidity
|
-20℃ ~ 60℃/ 20% ~ 95% (non-condensing)
|
||
|
Conveyor Speed(m/s)
|
0.22
|
Operating voltage
|
220VAC (±10%) 50±3HZ
|
||
|
Noise
|
＜55dB
|
Power loss
|
0.5KW (maximum)
|
||
