Quick Details
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
2200*1000*1300
-
Machine Weight:
-
850 kg
-
Bucket capacity:
-
0.15cbm
-
Marketing Type:
-
New Product2023
-
Model:
-
SLM-T460D
-
Motor rated power KW:
-
6.5KW
-
Motor calibrated speed rpm:
-
2500
-
Battery capacity:
-
200AH
-
Charging time H:
-
1.5/2/4
-
Battery life:
-
8 years
-
Height to bucket pin:
-
1870
-
Maximum height of bucket when lying flat:
-
1810
-
Vehicle height:
-
1300
-
Operating weight:
-
1000 Kg
Quick Details
-
Engine Brand:
-
Other
-
Power:
-
Other, 6KW
-
Brand Name:
-
HIGHTOP
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
2200*1000*1300
-
Machine Weight:
-
850 kg
-
Bucket capacity:
-
0.15cbm
-
Marketing Type:
-
New Product2023
-
Model:
-
SLM-T460D
-
Motor rated power KW:
-
6.5KW
-
Motor calibrated speed rpm:
-
2500
-
Battery capacity:
-
200AH
-
Charging time H:
-
1.5/2/4
-
Battery life:
-
8 years
-
Height to bucket pin:
-
1870
-
Maximum height of bucket when lying flat:
-
1810
-
Vehicle height:
-
1300
-
Operating weight:
-
1000 Kg
Production line
Product Description
Specification
|
ITEMS
|
SPECIFICATIONS
|
ITEMS
|
SPECIFICATIONS
|
|
Battery brand
|
Forest Cat(Lithium iron phosphate)
|
Height at Maximum Extension
|
2450
|
|
Motor rated power
|
6KW
|
Height To the the bucket pin
|
1870
|
|
Motor nominal speed rpm
|
2500
|
Vehicle height
|
1350
|
|
Battery capacity
|
200AH
|
Maximum Height as Lay the bucket flat
|
1810
|
|
Charging time(h)
|
1.5/2/4
|
Total length without appendages
|
1680
|
|
Battery Life
|
5 years
|
Length With standard bucket
|
2206
|
|
Full working hours
|
4-6(h)
|
Maximum height unloading Angle
|
34°
|
|
Battery voltage(V)
|
72
|
Dumping Height
|
1510
|
|
Charging voltage (optional)(V)
|
110/220/380
|
Discharge Distance
|
450
|
|
Driving speed(km/h)
|
0-6
|
The flip Angle of the bucket on the ground
|
27°
|
|
Working speed(s)
|
9
|
Bucket flip Angle at highest Pos.
|
114°
|
|
Working system pressure(bar)
|
17-21
|
Wheel Base
|
850
|
|
Operating mass(Kg)
|
1200
|
Ground Clearance
|
150
|
|
Tire model
|
18*72
|
Tail Length
|
280
|
|
Wheel base
|
720
|
Bucket width
|
1000
|
|
Rated load(kg)
|
300
|
Breakout force KN
|
3.5
|
|
Maximum load(kg)
|
400
|
Bucket volume m³
|
0.12
|
