Quick Details
-
Brand Name:
-
CARSPA
-
Model Number:
-
MPPT12/24-20
-
Work Time (h):
-
24hours
-
Max PV Power:
-
240W
-
Max PV Voltage:
-
90V
-
Certificate:
-
CE/ROHS
-
Warranty:
-
24months
-
current:
-
20a
-
voltage:
-
12/24v
-
type:
-
MPPT
-
Battery type:
-
AGM, WET, GEL, Lithium battery MPPT
-
MPPT efficiency:
-
99.8%
-
Display:
-
LED
-
USB output:
-
no
-
OEM:
-
Accepted
-
Charge way:
-
3 stage mppt charging
Quick Details
-
Type:
-
MPPT
-
Application:
-
Charger Controller, Voltage Controller, Solar System Controller
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CARSPA
-
Model Number:
-
MPPT12/24-20
-
Work Time (h):
-
24hours
-
Max PV Power:
-
240W
-
Max PV Voltage:
-
90V
-
Certificate:
-
CE/ROHS
-
Warranty:
-
24months
-
current:
-
20a
-
voltage:
-
12/24v
-
type:
-
MPPT
-
Battery type:
-
AGM, WET, GEL, Lithium battery MPPT
-
MPPT efficiency:
-
99.8%
-
Display:
-
LED
-
USB output:
-
no
-
OEM:
-
Accepted
-
Charge way:
-
3 stage mppt charging
20A MPPT type Solar charge controller
| Model | MPPT12/24-20 |
| Normal voltage | 12/24V, automatic recognition |
| Nominal battery charge current | 2 0A |
| Max. PV input power | 24 0W@12V 48 0W@24V |
| Max.solar input voltage Voc | > 30V/48V |
| Min.solar input voltage Vmp | >16V/32V |
| Power conversion efficiency | Max. 90% |
| Standby power consumption | < 20mA |
| Length≤ 1m charge loop drop | <0.25V |
| Length≤ 1m discharge loop drop | <0.05V |
| Temperature compensation | -3 mv/cell *K |
| LCD screen display | Battery voltage, PV charge current, Load discharge current, total PV charge Ah, total PV discharge Ah, the setting of constant voltage charging, the setting of low voltage disconnect, the setting of low voltage reconnect |
| Buttons | Menu, Load( on/off), Up, Down |
| Dimensions | 172*126*75mm(L*W*H) |
| Weight | 790 g |
| Ambient temperature range | -40 to +50°C |
| Case protection | IP22 |
| Float charge | 13.7V/27.4V(default) |
| Bulk charge | 14.8V/29.6V(default) |
| Equalization charge | 14.6V/29.2V(default) |
| Grounding | Positive grounding |
| Battery type | GEL,AGM, Solar battery etc. |
