Quick Details
-
Brand Name:
-
GAIN EXPRESS
-
Model Number:
-
GM-268
-
Type:
-
Gloss Meter
-
Display:
-
4 Digits Back-light LCD
-
Measuring Geometry:
-
20 / 60 / 85 Degrees
-
Range:
-
0.1 ~ 200 Gloss Units
-
Gloss Units:
-
GU
-
Resolution:
-
0.1 GU
-
Repeat ability:
-
±0.5 GU
-
Data Memorized:
-
254 Groups
-
Power Supply:
-
3.7V Built-in Rechargeable Battery
Quick Details
-
Warranty:
-
1 Year
-
Power:
-
3.7V Built-in Lithium Ion Rechargeable Battery
-
Place of Origin:
-
China
-
Brand Name:
-
GAIN EXPRESS
-
Model Number:
-
GM-268
-
Type:
-
Gloss Meter
-
Display:
-
4 Digits Back-light LCD
-
Measuring Geometry:
-
20 / 60 / 85 Degrees
-
Range:
-
0.1 ~ 200 Gloss Units
-
Gloss Units:
-
GU
-
Resolution:
-
0.1 GU
-
Repeat ability:
-
±0.5 GU
-
Data Memorized:
-
254 Groups
-
Power Supply:
-
3.7V Built-in Rechargeable Battery
Product Description
What does a gloss meter measure?
A glossmeter (also gloss meter) is an instrument which is used to measure the specular reflection (gloss) of a surface. Gloss is determined by projecting a beam of light at a fixed intensity and angle onto a surface and measuring the amount of reflected light at an equal but opposite angle.
Features:
* In accordance with international standard ASTMD523, ASTMD1455, ASTMC346, ASTMC584, ASTMD2457, DIN ENISO2813, DIN67530,
ENISO7668, JISZ8741, MFT30064, TAPPIT480, GB9754, GB/T13891, GB7706 and GB8807. Its technical parameters conform with
JJG696-2002.
* Accurate measurement, good repetitiveness.
* Small in size, easy to carry.
* Auto calibration.
* Intelligent design, rapid measurement.
* Able to store 254 groups of measurements.
* Built-in lithium ion rechargeable battery.
* Back-light display, suitable for low light environment
ENISO7668, JISZ8741, MFT30064, TAPPIT480, GB9754, GB/T13891, GB7706 and GB8807. Its technical parameters conform with
JJG696-2002.
* Accurate measurement, good repetitiveness.
* Small in size, easy to carry.
* Auto calibration.
* Intelligent design, rapid measurement.
* Able to store 254 groups of measurements.
* Built-in lithium ion rechargeable battery.
* Back-light display, suitable for low light environment
Specification
Customized support
|
OEM
|
Place of Origin
|
China
|
Model Number
|
GM-268
|
Power
|
3.7V Built-in Lithium Ion Rechargeable Battery
|
Type
|
Gloss Meter
|
Display
|
4 Digits Back-light LCD
|
Measuring Geometry
|
20 / 60 / 85 Degrees
|
Range
|
0.1 ~ 200 Gloss Units
|
Gloss Units
|
GU
|
Resolution
|
0.1 GU
|
Repeat ability
|
±0.5 GU
|
Data Memorized
|
254 Groups
|
Power Supply
|
3.7V Built-in Rechargeable Battery
|
Measuring Geometry
|
20 / 60 / 85 Degrees (GM-6: 60 Degrees, GM-26: 20 Degrees and 60 Degrees)
|
Accuracy
|
±1.0 GU
|
Measuring Area
|
7 x 14 mm (Ellipse)
|
Data Memorized
|
254 Groups
|
* Working Condition
|
* Temperature : 0 ~ 40°C
|
|
* Humidity : <85%
|
Details Images
