Quick Details
-
Type:
-
with water feeder
-
Maximum size:
-
575*7230MM
-
Net weight:
-
14KG
-
Working mode:
-
motor
-
Operating voltage:
-
24V
-
Battery life:
-
3-4h Affected by working environment and season
-
Length of telescopic rod:
-
7200MM
-
Charging voltage:
-
220V/110V
-
Product name:
-
Solar Cleaning Machine
-
Application:
-
Clean Solar Photovoltaic Panels
Quick Details
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Sunway
-
Model Number:
-
C21-7200
-
Type:
-
with water feeder
-
Maximum size:
-
575*7230MM
-
Net weight:
-
14KG
-
Working mode:
-
motor
-
Operating voltage:
-
24V
-
Battery life:
-
3-4h Affected by working environment and season
-
Length of telescopic rod:
-
7200MM
-
Charging voltage:
-
220V/110V
-
Product name:
-
Solar Cleaning Machine
-
Application:
-
Clean Solar Photovoltaic Panels
C21
Solar cleaning machine, which is designed and made for the special environment of photovoltaic power station.
It is suitable for barren mountain power station , distributed power station and farming photovoltaic power station within meters where the big solar panel cleaning system can't get into.
Specification
|
Item
|
|
C21-3600
|
C21-5400
|
C21-7200
|
|||
|
Product Parameters
|
Type
|
With water feeder
|
|
|
|||
|
|
Minimum size
|
575*2330mm
|
|
|
|||
|
|
Maximum size
|
575*3630mm
|
575*5430mm
|
575*7230mm
|
|||
|
|
Net weight
|
12KG
|
13KG
|
14KG
|
|||
|
|
Gross weight
|
13KG
|
14KG
|
15KG
|
|||
|
|
Carton size
|
2030* 170*420MM
|
|
|
|||
|
Technical
Parameters |
Working mode
|
Motor
|
|
|
|||
|
|
Operating voltage
|
24V
|
|
|
|||
|
|
Charging voltage
|
220V/110V
|
|
|
|||
|
|
Motor power
|
200W
|
|
|
|||
|
|
Battery capacity
|
20Ah
|
|
|
|||
|
|
ldler electric current
|
7~8A
|
|
|
|||
|
|
ldler revolutions
|
500~600rpm
|
|
|
|||
|
|
Battery life
|
3~4h Affected by
workingenvironment and season
|
|
|
|||
|
|
Length of brush roller
|
ф 150*570*400mm
|
|
|
|||
|
|
Length of telescopic rod
|
3600mm
|
5400mm
|
7200mm
|
|||
|
|
Day work efficiency
|
0.5~0.8MW
|
|
|
|||
|
|
Work temperature range
|
30~60℃
|
|
|
|||
|
Accessories |
|
Backpack
|
|
|
|||
|
|
|
Tool bag
|
|
|
|||
|
HS Code
|
|
8424899900
|
|
|
|||
Product Details
Daily cleaning 800KW, about 2500 solar panels, power generation efficiency increased by 10%
Application
The product has the advantages of
low cost
,
easy using
and
high efficiency
of daily cleaning O.5MW-O.8MW. Besides , there are 2 cleaning methods options ,
water and dry cleaning
,which provide user with a
one-stop solution
for photovoltaic power station cleaning.
Project Case
Product Packing
Certification
