Quick Details
-
Brand Name:
-
Juniper
-
Model Number:
-
EX9208-RED3B-AC
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Juniper Networks EX9208-RED3B-AC Switch
-
System throughout:
-
Up to 12.8 Tbps (bidirectional)
-
Forwarding capacity:
-
Up to 4.2 Bpps
-
QSFP+/QSFP28 ports:
-
64 QSFP+ or QSFP28
-
25GbE (breakout cable, QSFP28):
-
128
-
10GbE (breakout cable, QSFP+):
-
128+2
-
Rack units:
-
2 U
-
Operating system:
-
Junos OS
-
CPU:
-
Intel Broadwell-DE, 4 Core, 2.2 GHz, 16 GB DDR4, 100 GB SSD
-
Management interfaces:
-
1 RJ-45 management port provided
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
Other
-
Brand Name:
-
Juniper
-
Model Number:
-
EX9208-RED3B-AC
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Juniper Networks EX9208-RED3B-AC Switch
-
System throughout:
-
Up to 12.8 Tbps (bidirectional)
-
Forwarding capacity:
-
Up to 4.2 Bpps
-
QSFP+/QSFP28 ports:
-
64 QSFP+ or QSFP28
-
25GbE (breakout cable, QSFP28):
-
128
-
10GbE (breakout cable, QSFP+):
-
128+2
-
Rack units:
-
2 U
-
Operating system:
-
Junos OS
-
CPU:
-
Intel Broadwell-DE, 4 Core, 2.2 GHz, 16 GB DDR4, 100 GB SSD
-
Management interfaces:
-
1 RJ-45 management port provided
Juniper Networks EX9208-RED3B-AC Ethernet Switch
Juniper Networks EX9208 Ethernet Switches provide high performance, scalable connectivity, and carrier-class reliability for high-density environments such as campus-aggregation and data-center networks. The EX9208 switch has a throughput of up to 4.8 terabits per second (Tbps) or up to 240 gigabits per second (Gbps) per slot full duplex. The EX9208 switch is a modular system that provides high availability and redundancy for all major hardware components, including Routing Engine modules (RE modules), Switch Fabric modules (SF modules), fan tray (redundant fans), and power supplies.
You can manage EX9208 switches by using the same interfaces that you use for managing other devices running the Juniper Networks Junos operating system (Junos OS)—the CLI, the Network and Security Manager (NSM), and Junos Space.
-
Chassis with craft interface and midplane
-
Two EX9200-SF2 modules
-
Two EX9200-RE2 modules
-
One fan tray
-
Four 2520 W DC power supplies
-
Blank panels for line card slots
| Power Supply | Input Voltage | Output Power |
| 2520 W AC | Low-voltage line (100–120 VAC) | 1167 W |
| High-voltage line (200–240 VAC) | 2050 W | |
| 2400 W DC | –40 VDC through –70 VDC | 2400 W to 2600 W |
