2.
Low energy consumption
3.
High efficiency
4.Easy to operate
- Product Details
- {{item.text}}
Quick Details
-
Excavation Width:
-
4800 3500mm
-
Excavation Distance:
-
1820 1530 mm
-
Excavation Height:
-
2570 2300 mm
-
Excavation Depth:
-
480 320 mm
-
Unloading Height:
-
1470-1646 (Variable)mm
-
Unloading Distance:
-
1600 (Variable) mm
-
Travelling Speed(m/min):
-
2-4.5
-
Motor Power(kw):
-
22
-
Loading capacity:
-
60-100
-
MIN.TURNING RADIUS(MM):
-
5500
Quick Details
-
Weight (KG):
-
20000
-
Place of Origin:
-
SHDONG
-
Brand Name:
-
MINGKO
-
Excavation Width:
-
4800 3500mm
-
Excavation Distance:
-
1820 1530 mm
-
Excavation Height:
-
2570 2300 mm
-
Excavation Depth:
-
480 320 mm
-
Unloading Height:
-
1470-1646 (Variable)mm
-
Unloading Distance:
-
1600 (Variable) mm
-
Travelling Speed(m/min):
-
2-4.5
-
Motor Power(kw):
-
22
-
Loading capacity:
-
60-100
-
MIN.TURNING RADIUS(MM):
-
5500
FEATURES AT A GLANCE
1.safe and environmentally friendly
PRODUCT SPECIFICATIONS
|
No
|
MK60
|
MK80
|
MK100
|
|
Excavating Width(mm):
|
3870
|
4800
|
4200
|
|
Uninstall Length(mm):
|
1530
|
1850
|
1600
|
|
Excavating Height(mm):
|
2300
|
2800
|
1800-2850
|
|
Excavating Depth(mm):
|
≥450
|
≥500
|
≥500
|
|
Unload Height(mm):
|
1400(Changeable)
|
1700(Changeable)
|
1100(Changeable)
|
|
Minimum Loading Height(mm):
|
1350（can add）
|
1200-1600(Changeable)
|
1200-1600(Changeable)
|
|
Unload Distance(mm):
|
1600(Changeable)
|
1700(Changeable)
|
1700(Changeable)
|
|
Maximum Rotation Angle(°):
|
±50
|
±50
|
±50
|
|
Weight(T):
|
7.8T
|
8.6T
|
9T
|
|
Loading Capacity(m³/hour):
|
60
|
80
|
100
|
|
Climbing Ability(°):
|
≤20
|
≤20
|
≤20
|
|
Travelling Speed(m/min):
|
2-4.5
|
2-4.5
|
2-4.5
|
|
Motor Power(kw):
|
22
|
30/37
|
30/37
|
|
Max. Material passing Size(LxWxH) (mm):
|
680*580*500
|
650*700*650
|
800x780x800
|
|
Ground Clearance(mm):
|
200
|
230(Changable)
|
200
|
|
Applied Working Section(W*H) (m):
|
≥2x2
|
≥2.2x2.2
|
≥2x2
|
|
Nominal Working Pressure(Mpa):
|
20
|
25
|
25
|
|
Conveying Mode:
|
Scraper/Leather Belt
|
Scraper/Leather Belt
|
Scraper/Leather Belt
|
PRODUCT CONFIGURATION
SALES AND SERVICE NETWORK
Successful Project
Project in Thailand
Project in India
Project in Russia
SIMILAR PRODUCTS
Our Advantages
Minko Machinery conducts business in South America, Southeast Asia, Europe, North America, and other parts of the world, and strives to be a global high-quality service provider in mining machinery, construction machinery, agricultural machinery, etc.
