WS-C2960L-24PS-AP for Cisco Ethernet Switch 24 Port POE GigE 2x 1G SFP Up Link

FOB Reference Price: Get Latest Price

≥2 Pieces

US $700

Free Inquiry

Customized Request

Quick Details

Product Description

WS-C2960L-24PS-AP Specification
Configurations
10/100/1000 Ethernet Ports	24
Uplink Interfaces	4 SFP
Available PoE Power	195W
Fanless	Y
Dimensions (H x D x W)	1.73 x 10.45 x 17.5 in. (4.4 x 26.5 x 44.5 cm)
Net Weight	7.63 lb (3.46 kg)
Console Ports
RJ45 Ethernet	1
USB mini-B	1
USB-A port for storage and Blueto0th console	1
Memory and Processor
CPU	ARMv7 800 MHz
DRAM	512 MB
Flash memory	256 MB
Performance
Forwarding bandwidth	28 Gbps
Switching bandwidth	56 Gbps
Forwarding rate (64-byte L3 packets)	41.67 Mpps
Unicast MAC addresses	8K
Maximum active VLANs	64
VLAN IDs available	4094
Maximum STP instances	64
Maximum SPAN sessions	1
MTU-L3 packet	9198 bytes
Jumbo Ethernet frame	10,240 bytes
MTBF in hours (Data)	2,412,947
MTBF in hours (PoE)	909,838
