Quick Details
-
Worktable Length:
-
85.4" / 2170mm
-
Worktable Width:
-
74.8" /1900mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JINTUO AUTO TECH
-
Model Number:
-
J-2012
-
Warranty:
-
12 Months
-
Product name:
-
straightening frame machine
-
Kinds of clamps:
-
Standard Clamps 2 Pcs
-
Air supply required:
-
0.8MPa
-
Chain Size:
-
12mm thick
-
surface finishing:
-
powder coating
-
Color:
-
Customizable
-
platform size:
-
Customizable
-
Certification:
-
CE Approved Frame Machine
-
Using range:
-
Small Body shop
-
Package:
-
Wooden Box
Quick Details
-
Weight:
-
688lbs /312kgs
-
Bench Height:
-
7.87" / 200mm
-
Max. Lifting Capacity:
-
6600lbs / 3000kgs
-
Worktable Length:
-
85.4" / 2170mm
-
Worktable Width:
-
74.8" /1900mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JINTUO AUTO TECH
-
Model Number:
-
J-2012
-
Warranty:
-
12 Months
-
Product name:
-
straightening frame machine
-
Kinds of clamps:
-
Standard Clamps 2 Pcs
-
Air supply required:
-
0.8MPa
-
Chain Size:
-
12mm thick
-
surface finishing:
-
powder coating
-
Color:
-
Customizable
-
platform size:
-
Customizable
-
Certification:
-
CE Approved Frame Machine
-
Using range:
-
Small Body shop
-
Package:
-
Wooden Box
Product Overview
Product Description
2. Pull down the steering mechanism, can be stretched and repaired under different positions
3. The position and height of the main fixture can be adjusted, and the clamping is firm and convenient.
4. High-power pneumatic hydraulic pump with strong power.
5. 180 degree rotatable pull tower, no dead angle stretching.
6. The surface of electrostatic spray, beautiful and durable.
7. Zigzag chain fixing system to facilitate the height adjustment of the chain.
8. With CE certificate.
Please consult the product manager for more product functions and introductions!
Specification
|
Portable Car Frame Machine Specification
|
|
|
|
Length of Platform
|
118"/3000mm
|
|
|
Width of Platform
|
78.7"/2000mm
|
|
|
Height of Platform
|
7.87"/200mm
|
|
|
Air Supply required
|
100-120PSI(0.6-0.8Mpa)
|
|
|
Hydraulic Power
|
5000PSI(35Mpa)
|
|
|
Pulling Capacity of Tower
|
10Ton
|
|
|
Range of Tower
|
180。
|
|
|
Max Loading Capacity
|
6600lbs/3000kgs
|
|
