Quick Details
-
Brand Name:
-
WAKAMATSU
-
Connection:
-
Female
-
Body material:
-
SS304
-
Working pressure:
-
4.00MPA Max
-
Size:
-
1/4-4inch
-
Usage:
-
Oil Gas Water Industrial
-
Temperature:
-
15~+100
-
Valve type:
-
Mini Valve
-
Thread:
-
NPT BSPT PT BSPP
-
MOQ:
-
50pcs
-
Packing:
-
Box
Quick Details
-
Port Size:
-
1/8 to 1
-
Place of Origin:
-
Shanghai, China
-
Model Number:
-
WV203FM
-
Brand Name:
-
WAKAMATSU
-
Connection:
-
Female
-
Body material:
-
SS304
-
Working pressure:
-
4.00MPA Max
-
Size:
-
1/4-4inch
-
Usage:
-
Oil Gas Water Industrial
-
Temperature:
-
15~+100
-
Valve type:
-
Mini Valve
-
Thread:
-
NPT BSPT PT BSPP
-
MOQ:
-
50pcs
-
Packing:
-
Box
Details Images
|
Permissible pressure
|
|
|
|
|
||||
|
Water, oil, gas at room temperature,
|
|
|
5.49Mpa
|
|
||||
|
Saturated steam
|
|
|
0.5Mpa
|
|
||||
|
Sealing inspection pressure
|
|
|
0.59Mpa
|
|
||||
|
Temperature range for use
|
|
|
-20 ℃~180 ℃
|
|
||||
|
Name
|
Thread(R.RC) Size
|
D
|
L
|
H
|
S
|
W
|
|
WM203FM-1/8
|
1/8
|
7.0
|
40
|
26.5
|
21
|
22.8
|
|
WM203FM-1/4
|
1/4
|
|
|
|
|
|
|
WM203FM-3/8
|
3/8
|
|
|
|
|
|
|
WM203FM-1/2
|
1/2
|
9.2
|
46
|
28.3
|
24
|
|
|
WM203FM-3/4
|
3/4
|
12.5
|
54
|
31.5
|
31.5
|
|
|
WM203FM-1
|
1
|
15.0
|
62
|
34.0
|
37
|
|
Manufacturing Technique
Product packaging
