Quick Details
-
Panel Dimensions:
-
674*403*55mm(fold) /2750*674*5mm( unfold)
-
Panel Efficiency:
-
22%
-
Peak Power(Pmax):
-
100/120/150/160/200/250/300Wp
-
Operating Voltage(Vmp):
-
18V
-
Working Current(Imp):
-
5.56/6.67/8.33/8.89/11.11/13.89/16.67A
-
Open Circuit Voltage(Voc):
-
21V(100/120W),21.6V(150/160/200/250/300W)
-
Short Circuit Current(Isc):
-
6.11/7.33/9.17/9.78/12.22/15.28/18.33A
-
Temperature Range:
-
-40℃~+70℃
-
Output Connector:
-
DC5.5*2.1,USB(100/120W),MC4(150/160/200/250/300W)
-
Net Weight:
-
4/4/5.1/5.4/6.2/7.3/8.4Kg
Quick Details
-
Brand Name:
-
OEM/ODM
-
Model Number:
-
SFZD-100-300B
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
674*403*55mm(fold) /2750*674*5mm( unfold)
-
Panel Efficiency:
-
22%
-
Peak Power(Pmax):
-
100/120/150/160/200/250/300Wp
-
Operating Voltage(Vmp):
-
18V
-
Working Current(Imp):
-
5.56/6.67/8.33/8.89/11.11/13.89/16.67A
-
Open Circuit Voltage(Voc):
-
21V(100/120W),21.6V(150/160/200/250/300W)
-
Short Circuit Current(Isc):
-
6.11/7.33/9.17/9.78/12.22/15.28/18.33A
-
Temperature Range:
-
-40℃~+70℃
-
Output Connector:
-
DC5.5*2.1,USB(100/120W),MC4(150/160/200/250/300W)
-
Net Weight:
-
4/4/5.1/5.4/6.2/7.3/8.4Kg
We have 10 years of customization experience, such as logo, color, pattern, packaging,own design, thank you card, label, etc.
Meet your various needs. Our strength lies low MOQ, 3~7 days sample, fast delivery.
Please contact us to tell your needs.
Product Parameters
| Specification | SFZD-120B | SFZD-150B | SFZD-160B | SFZD-200B | SFZD-250B | SFZD-300B |
| Peak Power(Pmax) | 120Wp | 150Wp | 160Wp | 200Wp | 250Wp | 300Wp |
| Working Voltage(Vmp) | 18V | 18V | 18V | 18V | 18V | 18V |
| Working Current(Imp) | 6.67A | 8.33A | 8.89A | 11.11A | 13.89A | 16.67A |
| Open Circuit Voltage(Voc) | 21V | 21.6V | 21.6V | 21.6V | 21.6V | 21.6V |
| Short Circuit Voltage(Isc) | 7.33A | 9.17A | 9.78A | 12.22A | 15.28A | 18.33A |
| Cells | Mono | Mono | Mono | Mono | Mono | Mono |
| Temperature Range | -40℃~+70℃ | -40℃~+70℃ | -40℃~+70℃ | -40℃~+70℃ | -40℃~+70℃ | -40℃~+70℃ |
| Connecting Cable | 2*22AWG | 2*22AWG | 2*22AWG | 2*22AWG | 2*22AWG | 2*22AWG |
| Output Connector |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
| Folding Size | 528*350*45mm | 674*403*40mm | 635*350*45mm | 674*403*45mm | 674*403*50mm | 674*403*55mm |
| Spread Size | 1650*528*5mm | 1460*674*5mm | 1650*635*5mm | 1884*674*5mm | 2315*674*5mm | 2750*674*5mm |
| Net Weight | 4Kg | 5.1kg | 5.4kg | 6.2kg | 7.3kg | 8.4kg |
| 10-year Experienced Manufacturer |
Chongqing Melidy Co., Ltd.
Chongqing Melidy Co., Ltd., founded in 2011, is a professional manufacturer oriented to provide our customers high quality products and services. We have cooperated more than 1000 customers in related industries. We can provide OEM & ODM customization services according to our customers' requirements. Looking forward to your cooperation. Thank you!
