- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
PLAYLITE
-
Model Number:
-
SP-005-0800-AH
-
Product Weight（kg）:
-
0.373
-
Product Dimension:
-
182x81x43 mm
-
Packing Dimension:
-
208*105*70 mm
-
PCs/ Ctn:
-
24
-
Input Voltage(V):
-
AC 100-240V
-
Color Temperature(CCT):
-
2700K,3000K,4000K,6000K
-
Lamp Luminous Efficiency(lm/w):
-
53-60
-
Lamp Luminous Flux(lm):
-
190-210 lm
-
CCT:
-
2700K,3000K,4000K,6000K
-
Luminous flux:
-
190-210 lm
-
Lamp Powe:
-
8W
-
Input Voltage:
-
AC 100-240V
-
Insulation class:
-
Class I
-
IP Rating:
-
IP 65
-
Warranty:
-
3 Years
-
LED type:
-
42 PCS 2835SMD LED
-
Net weight:
-
0.373 kgs
-
Certifications:
-
CE, RoHS
Quick Details
-
Application:
-
Hotel
-
Design Style:
-
Modern
-
Lamp Body Material:
-
Aluminum
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
PLAYLITE
-
Model Number:
-
SP-005-0800-AH
-
Product Weight（kg）:
-
0.373
-
Product Dimension:
-
182x81x43 mm
-
Packing Dimension:
-
208*105*70 mm
-
PCs/ Ctn:
-
24
-
Input Voltage(V):
-
AC 100-240V
-
Color Temperature(CCT):
-
2700K,3000K,4000K,6000K
-
Lamp Luminous Efficiency(lm/w):
-
53-60
-
Lamp Luminous Flux(lm):
-
190-210 lm
-
CCT:
-
2700K,3000K,4000K,6000K
-
Luminous flux:
-
190-210 lm
-
Lamp Powe:
-
8W
-
Input Voltage:
-
AC 100-240V
-
Insulation class:
-
Class I
-
IP Rating:
-
IP 65
-
Warranty:
-
3 Years
-
LED type:
-
42 PCS 2835SMD LED
-
Net weight:
-
0.373 kgs
-
Certifications:
-
CE, RoHS
Product Description:
.
42
PCS
2835 SMD
LED
with high lumen and beautiful light output.
. tempered glass with high loading capacity.
.20~25 um thickness passivated anti-corrosion protection film that won't be fading even after 2 to 3 years
.
Asymmetric downward 120°
beam angle as options
.
19
0
-21
0 lm
luminous flux output
.
IP6
5
waterproof
. 3 years warranty
.8~10 years professional sales and technicians to serve you
Data sheet:
|
General Data |
|
|
Item No. |
SP-005-0800-AH |
|
Power |
8 Watts |
|
LED type |
42 PCS 2835 SMD LED |
|
Luminous flux |
190-210 lm |
|
CCT |
2700K,3000K,4000K,6000K |
|
CRI |
80+ |
|
Beam angle |
120° |
|
Dimension |
182x81x43 mm (Length x Wide x Height) |
|
Cut out |
173 x 65 x 54.5 mm |
|
Net weight |
0.373 kgs |
|
Warranty |
3 years |
|
Certifications |
CE, RoHS |
|
Electrical Data |
|
|
Input voltage |
AC 100-240V |
|
Insulation class |
Class I |
|
Cable |
1 x cable 0.3 M H05RN-F 3x0.75mm square to open wires |
|
Driver |
Built-in high voltage constant current driver with transformer |
|
Construction Data |
|
|
IP rating |
IP65 Waterproof |
|
Housing |
Solid Passivated ( Anodizing ) Aluminum CNC machined |
|
Protection finishing |
20~25μ m thickness anodized film for housing .Dark grey |
|
Trim |
Tempered glass painted in milky white |
|
Glass |
Tempered Glass.T=4mm. |
|
Loading capacity |
320 kgs |
|
Cable Gland |
PG7 IP67 |
|
Gasket |
Flat PMQ silicone seal |
|
Accessories |
|
|
Mounting box |
Aluminum |
Photometric Data (3000K, 2x100°) & Illumination Picture
Application Pictures
