Quick Details
-
Brand Name:
-
UNIPRETEC
-
Color:
-
white
-
Density:
-
5.95 g/cm3
-
Moh's Hardness:
-
9
-
Max. Working Temperature:
-
<600 °C
-
Volume Resistivity ( at R.T. ):
-
>10^12 ohm.cm
-
Dielectric Constant ( 1 MHz at R.T. ):
-
26
Quick Details
-
Material:
-
Zirconia Ceramic
-
Place of Origin:
-
Fujian, China
-
Model Number:
-
17021302
-
Brand Name:
-
UNIPRETEC
-
Color:
-
white
-
Density:
-
5.95 g/cm3
-
Moh's Hardness:
-
9
-
Max. Working Temperature:
-
<600 °C
-
Volume Resistivity ( at R.T. ):
-
>10^12 ohm.cm
-
Dielectric Constant ( 1 MHz at R.T. ):
-
26
Material Introduction
Unlike traditional ceramics that tend to be hard and brittle, Zirconia offers high strength, wear resistance, and flexibility far beyond those of most other technical ceramics. Zirconia is a very strong technical ceramic with excellent properties in hardness, fracture toughness, and corrosion resistance; all without the most common property of ceramics – high brittleness.
There are several grades of Zirconia available, the most common of which are Yttria Partially Stabilized Zirconia (Y-PSZ) and Magnesia Partially Stabilized Zirconia (Mg-PSZ). Both of these materials offer excellent properties, however, the operating environment and part geometry will dictate which grade may be suitable for specific applications (more on this below). Its unique resistance to crack propagation and high thermal expansion make it an excellent material for joining ceramics with metals like steel. Due to Zirconia’s unique properties it is sometimes referred to as the “ceramic steel”.
Product Features
|
√ similar CTE to steel
|
√ high fracture toughness
|
|
√ extremely high hardness
|
√ high corrosion resistance
|
|
√ good electrical insulation
|
√ low coefficient of friction
|
|
√ excellent thermal insulation
|
√ outstanding wear resistance
|
Applications
Material Properties
|
ITEM
|
UNIT
|
Zirconia | YSZ95
|
|
Main Content
|
-
|
ZrO2 > 94.5%
|
|
Color
|
-
|
White / Black / Blue / Yellow
|
|
Density
|
g/cm
3
|
5.95
|
|
Vickers Hardness
|
Gpa
|
12
|
|
Flexural Strength
|
Mpa
|
800
|
|
Compressive Strength
|
Mpa
|
2,500
|
|
Electrical Resistivity
|
Ω·cm
|
>10
10
|
|
Dielectric Strength
|
KV/mm
|
9
|
|
Dielectric Constant
|
1 MHz
|
28
|
|
Thermal Conductivity
|
W/m.K
|
2.2
|
|
Max. Working Temperature
|
℃ / °F
|
800 / 1,470
|
|
Resistance to Thermal Shock
|
△T(℃)
|
260
|
|
Thermal Expansion Coefficient (25 - 1,000 ℃)
|
10
-6
/K
|
11 - 13
|
Inspection
About Us
UNIPRETEC is a representative technical ceramic company in China. Relying on the technical team with more than 10 years of experience and the cooperation of well-known domestic colleges and institutions, our company covers the manufacturing and sales of oxide, nitride and carbide ceramic products. Based on the research in the advanced ceramic industry, our company is good at providing suitable products and suggestions flexibly according to customers' applications and needs. For many years, our company has focused on meeting the needs of customers from all over the world. Many praises from customers and partners have been encouraging UNIPRETEC to move forward and develop.
