Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HaloPower OEM ODM
-
Model Number:
-
HALO P-1016Z, Brush Motor
-
Torque:
-
0.80/1.11N.m
-
Product Name:
-
MY1016Z Gear Motor
-
Application:
-
Wheel Chair ,lawn mower,BOAT, Cart, Electric Bicycle, Home Appliance
-
Power:
-
250W/350W/450W
-
Rated Voltage:
-
24V/36V
-
No-load Curernt:
-
≤2.2A
-
Efficinecy:
-
≥78%
-
Insulation:
-
Class B(130℃)
-
Using Humidity:
-
≤85%(Place without dew)
-
Noise:
-
Low Noise Level
Quick Details
-
Speed(RPM):
-
3850r/min
-
Continuous Current(A):
-
≤13.4/18.7A
-
Efficiency:
-
IE 2
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HaloPower OEM ODM
-
Model Number:
-
HALO P-1016Z, Brush Motor
-
Torque:
-
0.80/1.11N.m
-
Product Name:
-
MY1016Z Gear Motor
-
Application:
-
Wheel Chair ,lawn mower,BOAT, Cart, Electric Bicycle, Home Appliance
-
Power:
-
250W/350W/450W
-
Rated Voltage:
-
24V/36V
-
No-load Curernt:
-
≤2.2A
-
Efficinecy:
-
≥78%
-
Insulation:
-
Class B(130℃)
-
Using Humidity:
-
≤85%(Place without dew)
-
Noise:
-
Low Noise Level
Products Description
Model: MY1016Z
Types function: Wheelchairs; amusement apparatus; agricultural machinery ;
tricycle, balance car,electric bike,boat and other electric equioment.
Working principle: The hub is mounted with tongue and groove claws to achieve friction
Product introduction: Features small volume, low speed, high output torque, low noise, high reliability, easy maintenance, etc.
Working principle: The hub is mounted with tongue and groove claws to achieve friction
Product introduction: Features small volume, low speed, high output torque, low noise, high reliability, easy maintenance, etc.
Requires 11 teeth and 14 teeth, please note
|
Model
|
MY1016Z2
|
|
MY1016Z3
|
|
MY1018
|
|
|||||
|
Rated Power
|
250w
|
250w
|
350w
|
350w
|
450w
|
450w
|
|||||
|
Rated Voltage
|
24v dc
|
36v dc
|
24v dc
|
36v dc
|
24v dc
|
36v dc
|
|||||
|
Rated Speed
|
3000RPM
|
3000RPM
|
3000RPM
|
3000RPM
|
3000RPM
|
3000RPM
|
|||||
|
No Load Speed
|
3850RPM
|
3850RPM
|
3850RPM
|
3850RPM
|
4000RPM
|
4000RPM
|
|||||
|
Rated Current
|
≤13.4A
|
≤9.0A
|
≤18.7A
|
≤12.5A
|
≤24.7A
|
≤16.5A
|
|||||
|
No Load Current
|
≤2.2A
|
≤2.0A
|
≤2.2A
|
≤2.0A
|
≤2.5A
|
≤2.2A
|
|||||
|
Rated Torque
|
0.8N.m
|
0.8N.m
|
1.11N.m
|
1.11N.m
|
1.43N.m
|
1.43N.m
|
|||||
|
Efficiency
|
≥78%
|
≥78%
|
≥78%
|
≥78%
|
≥78%
|
≥78%
|
|||||
|
Gear Ration
|
7.18:1
|
|
|
|
|
|
|||||
