Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Techage/OEM
-
Model Number:
-
6916K-16-PT825-80P-NC-CP
-
Product name:
-
poe dome camera system
-
Lens:
-
3.6mm
-
NVR Power Supply:
-
48V
-
Alarm System:
-
Motion Detection + Email Alert +APP Push
-
Leds:
-
Built-in 6pcs LEDs & 6pcs IR LEDs & 1pcs Red LED & 1pcs Blue LED
-
IR Distance:
-
30m
-
APP:
-
XMeye or XMeye Pro
-
Hard Disk Drive (HDD):
-
1*SATA Port (Max 8TB)
-
Certification:
-
CE,FCC,ROHS
-
Channel:
-
16 Channels
Quick Details
-
Network:
-
Ip
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM, Software reengineering
-
Special Features:
-
PAN-TILT, Built-in Siren, NIGHT VISION, Two-way Audio, Human Motion Tracking, Motion Detection, Waterproof / Weatherproof
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Techage/OEM
-
Model Number:
-
6916K-16-PT825-80P-NC-CP
-
Product name:
-
poe dome camera system
-
Lens:
-
3.6mm
-
NVR Power Supply:
-
48V
-
Alarm System:
-
Motion Detection + Email Alert +APP Push
-
Leds:
-
Built-in 6pcs LEDs & 6pcs IR LEDs & 1pcs Red LED & 1pcs Blue LED
-
IR Distance:
-
30m
-
APP:
-
XMeye or XMeye Pro
-
Hard Disk Drive (HDD):
-
1*SATA Port (Max 8TB)
-
Certification:
-
CE,FCC,ROHS
-
Channel:
-
16 Channels
Product Description
Mian Features:
1. HD 4K POE Camera System. Support Motion Detection + Email Alert + Alarm Siren. Trigger multiple alarms at the same time to scare off intruders.
2. Support custom camera alarm sound or alarm bell.
3. 8 channel 4K NVR design, support to connect up to 8pcs 4K Cameras. You can buy Tinosec PoE IP cameras and a PoE Switch to expand your CCTV system to 16 channels.
4. Speed Dome PTZ camera, support to remote control pan 355°/ tilt 90° rotation.
5. Smart AI PoE camera, support human detection, humanoid auto tracking and red-blue light alarm.
6. The cameras have bulit in microphone and speaker, support two-way audio recording.
7. Three Night Vision Modes Setting: Infrared night vision, Dual warning lights, Full color night vision
8. P2P Multi-User Remote Access: P2P technology let you be able to view the live situation of your house wherever you are, just with the P2P account on the app via your Smartphone or tablet.
9. XMeye independently developed the RTS Cloud architecture, which is faster and the preview is more stable.
Package Included:
1 x 16CH 4K PoE NVR
16 x 8MP Cameras.
1 x Power Supply for NVR.
1 x USB Mouse for NVR.
1 x Remote Contorller for NVR.
1 x Network Cable for NVR.
1 x User Manual.
2/4/6/8 x Screw bags.
2 x Warning Sticker (gift).
2/4/6/8 x Waterproof Connector for Cable (gift).
No HDD / 1TB / 2TB / 3TB / 4TB HDD for Optional.
1. HD 4K POE Camera System. Support Motion Detection + Email Alert + Alarm Siren. Trigger multiple alarms at the same time to scare off intruders.
2. Support custom camera alarm sound or alarm bell.
3. 8 channel 4K NVR design, support to connect up to 8pcs 4K Cameras. You can buy Tinosec PoE IP cameras and a PoE Switch to expand your CCTV system to 16 channels.
4. Speed Dome PTZ camera, support to remote control pan 355°/ tilt 90° rotation.
5. Smart AI PoE camera, support human detection, humanoid auto tracking and red-blue light alarm.
6. The cameras have bulit in microphone and speaker, support two-way audio recording.
7. Three Night Vision Modes Setting: Infrared night vision, Dual warning lights, Full color night vision
8. P2P Multi-User Remote Access: P2P technology let you be able to view the live situation of your house wherever you are, just with the P2P account on the app via your Smartphone or tablet.
9. XMeye independently developed the RTS Cloud architecture, which is faster and the preview is more stable.
Package Included:
1 x 16CH 4K PoE NVR
16 x 8MP Cameras.
1 x Power Supply for NVR.
1 x USB Mouse for NVR.
1 x Remote Contorller for NVR.
1 x Network Cable for NVR.
1 x User Manual.
2/4/6/8 x Screw bags.
2 x Warning Sticker (gift).
2/4/6/8 x Waterproof Connector for Cable (gift).
No HDD / 1TB / 2TB / 3TB / 4TB HDD for Optional.
HD 4K Resolution
HD 4K camera can display fine image quality. The picture is clear and closer to the real scene.
Smart AI Human Detection + Red-Blue Light Alarm
When it detects a moving human body at night, 6pcs white LED lights will light up as a warning deterrent and provide a color surveillance video.
At the same time, the camera will sound alarm and the red and blue lights will flash alternately. Then the alarm messages will be sent to your mailbox.
High-precision Intelligent Identification and Alarm
Only valid for human movement. Animals and items do not trigger alarm.
Support Pan 355°/TIlt 90° Rotation
(1)Digital zoom camera with cruise covers 355° horizontal and 90° vertical range, monitoring your home or backyard from all angles. (2) No blind spot surveillance and never miss every detail in any corner.
Smart Human Auto Tracking & Daemon Position Setting
When somebody move, the camera automatically track the body. When the human disappears from the camera's field of view, the camera will automatically rotate back to the daemon position you set, monitor the position you focus on at all times.
Real-time Two-way Audio
Camera has built in Microphone and Speaker. Never miss a moment with your family.
Camera has built in Microphone and Speaker. Never miss a moment with your family.
Full Color Night Vision
When the 2 white LEDs are lit, the surveillance video at night will show a colorful picture.
Three night vision modes for you to choose: IR infrared night vision, dual warning lights, full color night vision
PTZ Cameras support IP66 Weatherproof
This Poe PTZ Camera has a solid body and housing, IP66 level waterproof rating makes it ideal for outdoor surveillance. It can stand harsh weather conditions. including rain, snow, intense cold and heat
Install and Connect it
It can be quickly and easily setup by anyone. Instantly see live video using your computer, tablet, or phone from anywhere.
Don't need extra power cables or adapters or switch.
It Can be Extended to 16pcs 5MP POE Camera if use 8CH POE Switch Together
Details Images
Specification
|
Model
|
XM-PT825-80P
|
|
|
|
Video |
Sensor
|
Embedded RTOS,dual-core 32bit DSP(NT98566),pure hard compression ,watch dog
|
|
|
|
Video compression
|
8.0M 1/2.7"SC501AI High Quality CMOS sensor, color 0.0001Lux@F1.2, black/white 0.0001Lux@F1.2
|
|
|
|
Image output
|
H.265AI/H.265+(Compatible with H.265/H.264), support dual stream, AVI;0.1M~8Mpbs variable;1~30f/s variable
|
|
|
|
Shutter
|
1/50(1/60) s to 1/10,000s
|
|
|
|
Noise reduction
|
Support 2D/3D
|
|
|
|
Wide dynamic
|
Support digital
|
|
|
|
Lens
|
3.6mm
|
|
|
|
Day and night
|
Support IR-CUT, IR-CUT coil has an internal resistance of 20 ohms, the power-on time is less than 200ma, and thevoltageis3.5V-6V
|
|
|
|
IR distance
|
20-30m
|
|
|
Audio
|
Audio compression
|
G.711, support bidirectional talk,audio&video synchronization
|
|
|
|
Audio interface
|
1ch input, level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone
|
|
|
PTZ |
Pan 355 degree Tilt 90 degree
|
|
|
|
|
Auto Human Tracking
|
|
|
|
Internet
|
Port
|
1*RJ45 10/100M adaptive Ethernet port; support RTSP/FTPDHCP/NTP/UPnP etc
|
|
|
Alarm |
Human detection, Motion detection, AI alarm.
|
|
|
|
|
Alarm Notification Push, Voice Alarm, Video Record, Snap Picture
|
|
|
|
|
Red Blue Light Alarm
|
|
|
|
Recording |
Time video, Event video
|
|
|
|
|
Time play back, Event play back
|
|
|
|
|
SD Card, up to 128GB. Cloud Storage
|
|
|
|
Other |
Reliability
|
Comprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing
|
|
|
|
ON-VIF
|
Support
|
|
|
|
Mobile monitoring
|
Support multiple mobile monitoring（iOS，Android）
|
|
|
|
Power
|
POE48V/DC12V 1A
|
|
|
|
Reset
|
Supports one-click reset
|
|
|
Environmental conditions
|
Temperature
|
-20℃ to +55℃
|
|
|
|
Humidity
|
30% to 80% RH
|
|
|
System
|
Main processor
|
Hi3536E
|
|
|
Operating System
|
Embedded Linux
|
|
|
System resources
|
Simultaneous multi-channel real-time
recording, playback, network operation, USB backup |
|
Interface
|
Operator interface
|
16-bit true color graphic menu operation
interface, support mouse operation |
|
|
Preview
|
1/2/4/6/8/9/16
|
|
Video
|
Video input (IP)
|
16*4K（Access bandwidth 72Mbps）
|
|
|
Video compression
|
H.265AI/H.265+(compatible H.265/H.264)
|
|
|
Display quality
|
Max:4K
|
|
|
Playback quality
|
4K/5M/4M/3M/1080P
|
|
|
VR
|
Unsupport
|
|
|
human shape / Face
|
Support(depend on camera)
|
|
Audio
|
Audio compression
|
G.711A
|
|
|
Intercom
|
unsupport
|
|
Record
& playback |
Recording mode
|
Manual>Alarm>Dynamic Detection>Timing
|
|
|
Localpayback(real-time+ Un
real-time) |
4K（1*real-time）/5M（1+1）/4M（2+1）/
3M（3+1）/1080P（5+1） |
|
|
Search mode
|
Search by Time/Calendar/Event/Channel/Face
|
|
|
Record storage
|
HDD、Network
|
|
|
Backup mode
|
Network backup, USB hard disk, USB burner,
SATA burner |
|
External
interface |
Video output
|
1ch VGA，1ch HD output
|
|
|
Audio I/O
|
0/1（3.5MM audio output）
|
|
|
Alarm I/O
|
0/0
|
|
|
Network interface
|
1*RJ45 10M/100M Adaptive Ethernet port
|
|
|
USB interface
|
2*USB2.0 ports(one USB extension
interface is reserved) |
|
|
HDD
|
1 SATA(Up to 14TB for each disk)
|
|
|
ESATA
|
No
|
|
|
Serial interface
|
No
|
|
Other
|
ON-VIF
|
Support
|
|
|
Power supply
|
12V/2A
|
|
|
Power Consumption
|
<10W(Without HDD)
|
|
|
Work environment
|
Temperature:0℃ －55℃ ,
Humidity:10%－90%RH , Atm:86kpa－106kp |
Packing & Delivery
Package Included:
1 x16CH 4K PoE NVR
16 x 8MP PoE IP Cameras.
1 x Power Supply for NVR.
1 x USB Mouse for NVR.
1 x Remote Contorller for NVR.
1 x Network Cable for NVR.
1 x User Manual.
2/4/6/8 x Screw bags.
2 x Warning Sticker (gift).
2/4/6/8 x Waterproof Connector for Cable (gift).
No HDD / 1TB / 2TB / 3TB / 4TB HDD for Optional.
