Quick Details
-
Panel Size:
-
960*960mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
OF
-
Usage:
-
OUTDOOR
-
Display Function:
-
Video
-
Pixels:
-
10mm
-
Screen Dimension:
-
960*960mm
-
Product name:
-
Led Video Display Panel
-
Certificate:
-
CE ROHS FCC
-
Brightness:
-
7500
-
Viewing angle:
-
140 /140
-
Input Voltage:
-
110 / 240
Quick Details
-
Application:
-
Indoor, Outdoor, Semi-outdoor
-
Brand Name:
-
LEDFUL
-
Color:
-
fullcolor, Fullcolor
-
Panel Size:
-
960*960mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
OF
-
Usage:
-
OUTDOOR
-
Display Function:
-
Video
-
Pixels:
-
10mm
-
Screen Dimension:
-
960*960mm
-
Product name:
-
Led Video Display Panel
-
Certificate:
-
CE ROHS FCC
-
Brightness:
-
7500
-
Viewing angle:
-
140 /140
-
Input Voltage:
-
110 / 240
Product Description
Product Paramenters
|
OF/OFR
|
OF2.5
|
OF3
|
OF3.076
|
OF3.91
|
OF4
|
OF4.81
|
OF5
|
||||||
|
Pixel Pitch(mm)
|
2.5
|
3
|
3.08
|
3.91
|
4
|
4.81
|
5
|
||||||
|
Pixel Matrix Per Sq.m
|
160000
|
111111
|
65436
|
65436
|
62500
|
62500
|
40000
|
||||||
|
Pixel Configuration
|
SMD1415
|
SMD1415
|
SMD1415
|
SMD1921
|
SMD1921
|
SMD1921
|
SMD1921
|
||||||
|
Brightness (nits)
|
5000
|
1800
|
5000
|
4000
|
5000 5500
|
4000
|
5500
|
||||||
|
Scan
|
1/16
|
1/16
|
1/13
|
1/16
|
1/10 1/8
|
1/13
|
1/8
|
||||||
|
Module Dimension
|
160x160mm
|
192x192mm
|
320x160mm
|
250x250mm
|
320x160mm 256x128mm
|
250x250mm
|
320x160mm
|
||||||
|
Cabinet Weight
|
46kg / 101lb (Iron)
|
46kg / 101lb (Iron)
|
45kg / 99lb (Iron)
|
44kg / 97lb (Iron)
|
44kg / 97lb (Iron)
|
43kg / 95lb (Iron)
|
43kg / 95lb (Iron)
|
||||||
|
Power Con. (Max / Avg)
|
900/ 180 w/sq.m
|
|
|
|
|
|
|
||||||
|
Cabinet Dimension
|
960x960mm （Cabinet size can be changed according to module size）
|
|
|
|
|
|
|
||||||
|
IP Rate
|
IP65
|
|
|
|
|
|
|
||||||
|
Service Access
|
Rear
|
|
|
|
|
|
|
||||||
|
Refresh Rate (HZ)
|
>1920
|
|
|
|
|
|
|
||||||
|
Grey Scale (bit)
|
16bit
|
|
|
|
|
|
|
||||||
|
Viewing Angle (H/V)
|
140/140
|
|
|
|
|
|
|
||||||
|
Input Voltage (AC)
|
110V/240V
|
|
|
|
|
|
|
||||||
|
OF/OFR
|
OF6
|
OF6.6
|
OF8
|
OF10S
|
OF10D
|
OF16S
|
OF16D
|
||||||
|
Pixel Pitch(mm)
|
6
|
6.67
|
8
|
10
|
10
|
16
|
16
|
||||||
|
Pixel Matrix Per Sq.m
|
27777
|
22500
|
15625
|
10000
|
10000
|
8000
|
10000
|
||||||
|
Pixel Configuration
|
SMD3535
|
SMD2727
|
SMD3535
|
SMD3535
|
DIP346
|
SMD3535
|
DIP346
|
||||||
|
Brightness (nits)
|
5500
|
5500
|
6500
|
6500
|
1000
|
8000
|
10000
|
||||||
|
Scan
|
1/8
|
1/6
|
1/3
|
1/2
|
1/2
|
1/1
|
1/1
|
||||||
|
Module Dimension
|
192x192mm
|
320x160mm
|
320x160mm
|
320x160mm
|
320x160mm
|
256x256mm
|
256x256mm
|
||||||
|
Cabinet Weight
|
42kg / 93lb (Iron)
|
42kg / 93lb (Iron)
|
41kg / 90lb (Iron)
|
40kg / 88lb (Iron)
|
40kg / 88lb (Iron)
|
46kg / 101lb (Iron)
|
46kg /101lb (Iron)
|
||||||
|
Power Con. (Max / Avg)
|
900/ 180 w/sq.m
|
|
|
|
|
|
|
||||||
|
Cabinet Dimension
|
960x960mm （Cabinet size can be changed according to module size）
|
|
|
|
|
|
|
||||||
|
IP Rate
|
IP65
|
|
|
|
|
|
|
||||||
|
Service Access
|
Rear
|
|
|
|
|
|
|
||||||
|
Refresh Rate (HZ)
|
>1920
|
|
|
|
|
|
|
||||||
|
Grey Scale (bit)
|
16bit
|
|
|
|
|
|
|
||||||
|
Viewing Angle (H/V)
|
140/140
|
|
|
|
|
|
|
||||||
|
Input Voltage (AC)
|
110V/240V
|
|
|
|
|
|
|
||||||
