Quick Details
-
Voltage:
-
380V
-
Gross Power:
-
13KW
-
Dimensions(L*W*H):
-
4800x2000x2400 mm
-
Weight:
-
6000KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Anilox roll:
-
Stell
-
Printing Plate:
-
Dycril plate
-
Material for printing:
-
Film,Paper.Al-foil
-
Pring plate lift:
-
Hydraulic press
-
Gear:
-
Helical gear
-
Unwinding and winding control:
-
Automatic tension control system
-
other:
-
as require
-
Name:
-
non woven fabric flexo printing machine
-
Certification:
-
CE,SGS,ISO9001:2000
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
GuoTai Machinery
-
Model Number:
-
YT Series
-
Voltage:
-
380V
-
Gross Power:
-
13KW
-
Dimensions(L*W*H):
-
4800x2000x2400 mm
-
Weight:
-
6000KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Anilox roll:
-
Stell
-
Printing Plate:
-
Dycril plate
-
Material for printing:
-
Film,Paper.Al-foil
-
Pring plate lift:
-
Hydraulic press
-
Gear:
-
Helical gear
-
Unwinding and winding control:
-
Automatic tension control system
-
other:
-
as require
-
Name:
-
non woven fabric flexo printing machine
-
Certification:
-
CE,SGS,ISO9001:2000
Best 4-Color Non Woven Bag Fabric Flexo Printing Machine for Sale
Flexo Printing Machine
Acceptable printing material:
LDPE : 28 ~ 100μm LLDPE : 30 ~ 100μm HDPE : 25 ~ 100μm
PVC : 25 ~ 70μm CPP : 20 ~ 60μm PP : 23 ~ 65μm
NY : 20 ~ 50μm PETP : 16 ~ 60μm OPP : 18 ~ 70μm
BOPP : 17 ~ 60μm OPA: 20 ~ 60μm Plating film : 30 ~ 80μm
Aluminum: 25 ~ 80μm Cellophane: 30 ~ 150g/m 2 Paper: 30 ~ 150g/m 2 Wrapping paper: 30 ~ 150g/m 2 Non-woven
Main Technical Variables:
|
Model of Machine
|
YT-4600
|
YT-4800
|
YT-41000
|
|
Max.Width of Printing Material
|
600mm
|
800mm
|
1000mm
|
|
Max.Printing With
|
560mm
|
760mm
|
960mm
|
|
Length Range of Printed Product
|
191-914mm
|
191-914mm
|
191-914mm
|
|
Max.Diameter of Roll Material
|
φ450mm
|
φ450mm
|
φ450mm
|
|
Printing Speed
|
550m/min
|
550m/min
|
550m/min
|
|
Thickness of plate(Including Two-sides Glue Paper)
|
2.38mm
|
2.38mm
|
2.38mm
|
|
Total Power
|
10.87kw
|
12.5kw
|
14.37kw
|
|
Weight of Machine
|
3000kg
|
3500kg
|
4000kg
|
|
Overall Dimensions
|
4200×1600×2400mm
|
4200×1800×2400mm
|
4200×2000×2400mm
|
