- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Water conservancy, river channels
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Jinling
-
Model Number:
-
C910
-
Type:
-
earthwork products
-
Thickness:
-
10mm
-
Roll Width:
-
2m
-
Roll Length:
-
10m-100m
-
Color:
-
Gray
-
OEM:
-
Acceptable
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Water conservancy, river channels
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Jinling
-
Model Number:
-
C910
-
Type:
-
earthwork products
-
Thickness:
-
10mm
-
Roll Width:
-
2m
-
Roll Length:
-
10m-100m
-
Color:
-
Gray
-
OEM:
-
Acceptable
One-stop Solutions
For Geosynthetic Materials
To Get The Best Price Please
Click Here
!
Product Description
|
Cement Blanket Specification
|
|
|
|
|
|
|||||
|
Product |
Weight (unset)
(kg/m2) |
Density (unset)
(g/m3) |
Density (set)(kg/m3)
|
Flexural strength
|
|
|||||
|
|
EN1849 (Mean)
|
EN1849 (Mean)
|
|
ASTM D8058 at 24 hours
|
|
|||||
|
|
|
|
|
Initial Break (MPa)
|
Final Break (MPa)
|
|||||
|
CC5
|
7.5
|
1.43-1.54
|
29.65
|
4
|
>10.0
|
|||||
|
CC10
|
15
|
1.43-1.54
|
29.65
|
4
|
>6.0
|
|||||
|
CC20
|
30
|
1.43-1.54
|
29.65
|
4
|
>4.0
|
|||||
|
Thickness
|
8mm/10mm/12mm
|
|
|
|
|
|||||
|
Weight
(kg/m2) |
Low Grade
|
10-16
|
|
|
|
|||||
|
|
High Grade
|
12-15
|
|
|
|
|||||
|
Type
|
G-high grade
|
D-low grade
|
S-cement blanket
|
L-sub grade
|
H-slope protection
|
|||||
|
Application
|
Ditch, Pool, Revetment, Pavement
|
|
|
|
|
|||||
Features
1. Easy construction.
Completed in only 4 steps: Cutting, laying, lapping, hydrating. No need for large machinery. Available in rolls or in bulk easy
for transportation, handling and installation.
for transportation, handling and installation.
2. Fireproof and UV resistant.
Classification of combustion properties of building materials and products: Class A.
UV aging resistance: 500 hours>95% strength retention
3. Eco-friendly and low carbon.
Compared with traditional methods, the amount of gravel is greatly reduced, and the CO2 is reduced by more than 90%.
4. Eco-friendly.
No need to deal with the foundation, adapt to deformation.
5. Labor and time saving.
The efficiency can reach 400
m
2
/day, work can be done by only 2 people, the tools are simple, no professional technology is needed. Rapid prototyping in any shape without multiple curing.
6. Strong and sturdy.
Compressive/reflex strength > C 30 concrete. Durable for 50 years.
7. Low cost.
Reduce labor costs and appliance costs. No cracking, settlement and dislocation.
Application
1. Ditch laying
2. Slope protection. Building foundation pit protection
3. Dam reinforcement
4. Reservoir, pond
5. Marine engineering tidal land
6. Sewage black and foul water cofferdam and river treatment
7. Sewage industry sewage related anti-corrosion and anti- erosion landfill leachate pool
8. Sandbag reinforcement, explosion-proof wall reinforcement
9. Light load path
10. Temporary diversion canal
11. Mine roadway support
12. Pipeline protection
13. Roof material
14. Low temperature and construction work
15. Flood control, dam reinforcement
2. Slope protection. Building foundation pit protection
3. Dam reinforcement
4. Reservoir, pond
5. Marine engineering tidal land
6. Sewage black and foul water cofferdam and river treatment
7. Sewage industry sewage related anti-corrosion and anti- erosion landfill leachate pool
8. Sandbag reinforcement, explosion-proof wall reinforcement
9. Light load path
10. Temporary diversion canal
11. Mine roadway support
12. Pipeline protection
13. Roof material
14. Low temperature and construction work
15. Flood control, dam reinforcement
FAQ
1. Thickness
Concrete blanket available in 3 thicknesses: CB6, CB8 and CB15, which are 6, 10 and 15mm thick respectively.
2. Roll size
Standard roll sizes are 1.25*42 m , 1.6*25 m, 2.0*25 m for option. Customize acceptable.
3. Color
The color can paint according to the requirements of projects.
4. Is it OK to install concrete blanket in water?
Concrete blanket is workable in water. Please kindly advise the hydrological conditions. We can provide professional solution on request.
Concrete blanket available in 3 thicknesses: CB6, CB8 and CB15, which are 6, 10 and 15mm thick respectively.
2. Roll size
Standard roll sizes are 1.25*42 m , 1.6*25 m, 2.0*25 m for option. Customize acceptable.
3. Color
The color can paint according to the requirements of projects.
4. Is it OK to install concrete blanket in water?
Concrete blanket is workable in water. Please kindly advise the hydrological conditions. We can provide professional solution on request.
