Quick Details
-
Weight:
-
17.5-56gsm
-
Model Number:
-
non-woven fabric
-
Product name:
-
Polyester non-woven fabric
-
Color:
-
Custom
-
Application:
-
For insulation material like dmd
-
MOQ:
-
1 ton
-
Sample:
-
Avaliable
-
Logo:
-
Custom
-
Place of Origin:
-
Xuchang, Henan
-
Package:
-
PE Film
Quick Details
-
Feature:
-
Flame Retardant, Anti-Pull
-
Pattern:
-
white
-
Use:
-
Industry, For electrical insulation material
-
Weight:
-
17.5-56gsm
-
Model Number:
-
non-woven fabric
-
Product name:
-
Polyester non-woven fabric
-
Color:
-
Custom
-
Application:
-
For insulation material like dmd
-
MOQ:
-
1 ton
-
Sample:
-
Avaliable
-
Logo:
-
Custom
-
Place of Origin:
-
Xuchang, Henan
-
Package:
-
PE Film
Product Introduction
Electrical Polyester Fiber Non-woven Fabric
Type: 7031 Electrical Non-Woven fabric
Thickness: 0.05mm-0.07mm
7031# Electrical Polyester Fiber Non-woven Fabric is constructed by mechanical carding forming net. The tensile strength of MD is much higher than that of TD.
Product Features:
Electrical Polyester Fiber Non-woven Fabric with the characters of low cost, light weight and good insulation.
Product details
|
Item
|
Units
|
Index
|
Index
|
Inner
|
Inner
|
|
Nominal thickness
|
mm
|
0.05
|
0.07
|
0.05
|
0.07
|
|
Thickness tolerance average
|
mm
|
±0.01
|
±0.01
|
±0.005
|
±0.005
|
|
Thickness tolerance individual
|
mm
|
±0.02
|
±0.02
|
±0.01
|
±0.01
|
|
Tensile force MD
|
N/50mm
|
≥60
|
≥80
|
60-85
|
80-150
|
|
Tensile force TD
|
N/50mm
|
≥20
|
≥25
|
20-30
|
25-45
|
|
Elongation at Break MD
|
%
|
≥6
|
≥8
|
9.5-18
|
16-26
|
|
Elongation at Break TD
|
%
|
≥3
|
≥5
|
6-11
|
6-13
|
|
Thermal shrinkage (150℃,1h) MD
|
%
|
≤4
|
≤4
|
0.2-1.0
|
0.2-1.0
|
|
Thermal shrinkage (150℃,1h) TD
|
%
|
≤3
|
≤3
|
0-1.0
|
0-1.0
|
Application
Electrical Polyester Fiber Non-woven Fabric is widely applicable for producing electrical insulation flexible laminates(such as DM, DMD, DMDM), mica tapes’ reinforced materials, the basic cloth of insulating varnish cloth, electrical laminated products, the coil terminal of electric motors wrapping, mini, soft cable & communication cable
