Quick Details
-
Available sizes:
-
300*300,300*600,300*1200,620*620,150*1200
-
Power:
-
20w,26w,50w,45w - below data
-
Thickness:
-
10mm - side emitting
-
Aluminum Frame:
-
6063
-
LED Viewing Angle:
-
120
-
Max Temp. rise:
-
≤25℃
-
Storage Temperature:
-
-20 to 60°C
-
Constant current driver:
-
20w / unit ( Meanwell optional )
-
Maintenance:
-
Available ( Free )
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Working Temperature(℃):
-
-20 - 40
-
Main Materials:
-
Aluminum frame, LED, LGP, power supply
-
Available sizes:
-
300*300,300*600,300*1200,620*620,150*1200
-
Power:
-
20w,26w,50w,45w - below data
-
Thickness:
-
10mm - side emitting
-
Aluminum Frame:
-
6063
-
LED Viewing Angle:
-
120
-
Max Temp. rise:
-
≤25℃
-
Storage Temperature:
-
-20 to 60°C
-
Constant current driver:
-
20w / unit ( Meanwell optional )
-
Maintenance:
-
Available ( Free )
40 watt smd LED panel light 600x600
Advantages:
1. High Luminous efficiency of up to 75~80LM / W, CRI >80
2. New aluminum frame design, ultra-thin 10mm, no screws on backside
3. AC100~240V operation with low voltage constant current driver
4. Suitable alternative to fluorescent lamp and traditional lighting sources
5. Energy-saving 60% for any indoor lighting;
6. Long life span up to 50,000hrs
7. No infrared rays, no ultraviolet radiation, little thermal effect;
8. Various dimensions are available;
9. Soft and wide light emitting;
10. Special circuit design, avoiding the single broken LED influence problem;
11. Instant start, no flickering, no humming, no RF interference.
12. Green LED item with RoHS & CE
13. Easy and convenient installation with Full accessories (mounting screws, lifting rope, clips)
14. Warranty 3 years
Applications:
LED panel lights are ideal for replacing conventional fittings in: Offices, meeting room, showroom, bedroom, schools, hospital, factory, workshop, lobby, metro, airport, corridor, hotels, restaurants, supermarkets and various places indoor lighting.
|
MODEL CCT |
Dimensions Power |
Luminous flux Lm |
Illuminance lux (Centre distance) depth |
Net weight |
||
|
1m |
2 m |
3m |
||||
|
RX-FT10-3030-CW 5800-6300K |
298x298x10mm 20W |
1600Lm |
580 |
180 |
98 |
1Kg |
|
RX-FT10-3030-WW 2800-3200K |
298x298x10mm 20W |
1500Lm |
550 |
170 |
92 |
|
|
RX-FT10-3060-CW 5800-6300K |
298x598x10mm 26W |
2100Lm |
750 |
220 |
97 |
2Kg |
|
RX-FT10-3060-WW 2800-3200K |
298x598x10mm 26W |
1950Lm |
712 |
210 |
92 |
|
|
RX-FT10-6060-CW 5800-6300K |
598x598x10mm 40W |
3200Lm |
1500 |
375 |
168 |
4Kg |
|
RX-FT10-6060-WW 2800-3200K |
598x598x10mm 40W |
3000Lm |
1420 |
356 |
159 |
|
|
RX-FT10-6262-CW 5800-6300K |
618x618x10mm 50W |
4200Lm |
1500 |
375 |
168 |
4.5Kg |
|
RX-FT10-6262-WW 2800-3200K |
618x618x10mm 50W |
3800Lm |
1420 |
356 |
159 |
|
|
RX-FT10-30120-CW 5800-6300K |
298x1198x10mm 45W |
3200Lm |
660 |
306 |
150 |
4Kg |
|
RX-FT10-30120-WW 2800-3200K |
298x1198x10mm 45W |
2800Lm |
625 |
290 |
142 |
|
