Quick Details
-
Brand Name:
-
Superlink / OEM
-
Model Number:
-
Lighting Control Cable
-
Cover Material:
-
PVC
-
Material Shape:
-
Round Wire
-
Conductor Type:
-
Stranded
-
Certification:
-
CE, ISO, RoHS, CCC, ETL, Reach
-
Length:
-
100m/200m/305m/500m
-
Wire Core Material:
-
Tinned Wire
-
Shield:
-
Al Foil
-
Specification:
-
multicore
-
Production Capacity:
-
5000km/Month
-
Transport Package:
-
PE Film/Wooden Reel/Plastic Drum
Quick Details
-
Conductor Material:
-
Tinned Copper
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Vietnam
-
Brand Name:
-
Superlink / OEM
-
Model Number:
-
Lighting Control Cable
-
Cover Material:
-
PVC
-
Material Shape:
-
Round Wire
-
Conductor Type:
-
Stranded
-
Certification:
-
CE, ISO, RoHS, CCC, ETL, Reach
-
Length:
-
100m/200m/305m/500m
-
Wire Core Material:
-
Tinned Wire
-
Shield:
-
Al Foil
-
Specification:
-
multicore
-
Production Capacity:
-
5000km/Month
-
Transport Package:
-
PE Film/Wooden Reel/Plastic Drum
Our service
1. All kinds of cable products & one-stop experience.
2. Quality & competitive price.
3. Order process will be shared via photo and video.
4. On-time delivery & After-sales problems solved before sales.
5. 24/7 hours response.
All start here
We have three factories located in Hangzhou, Shenzhen and Vietnam. The total production base exceeds 300,000 square meters. We
plan to set up offices in all coastal port cities in China to achieve fast delivery.
Connect the world
1. Hangzhou factory: "Quality first" pass tests.
2. Shenzhen factory: "Price first"
3. Vietnam factory: Export to EU, America, no tariffs, anti-dumping.
Our capability
1. 17 years of production experience, quality first, customer first, service first.
2. Swiss moulds with high precision are selected for production equipment.
3. Complete supply chain. We have our own raw material factory, from materials to finished products, offer more competitive pricing with good quality for customer.
|
Product
|
Km/year
|
Product
|
Ton/year
|
|
Network cable
|
500 000Km
|
Cu wire
|
1000T
|
|
Coaxial cable
|
380 000Km
|
CCA wire
|
100T
|
|
Speaker cable / alarm cable
|
200 000Km
|
CCS wire
|
500T
|
|
Telephone cable
|
150 000Km
|
AL-MG wire
|
300T
|
|
Power cable
|
210 000Km
|
AL foil
|
120T
|
|
Patch cord
|
110 000Pcs
|
PE compound
|
1000T
|
|
Solar cable
|
50 000Km
|
PVC compound
|
2500T
|
Product Description
Belden Equivalent Cable Electronic Audio Control Instrumentation Cable 8471, 8473, 8477
Belden Cable # 8471, 8473, 8477
Our cables are produced strictly under the same quality standards as Belde's, from inside out. If you need wire and cable that
requires Belden specifications but not the brand, we can provide the alternatives.
Application:
Wiring of Electronic, Audio, Control and Instrumentation.
Belden 8471, 8473, 8477 equals, NEC Type CMG CL3R FT4 (UL) c(UL) ETL
Physical Characteristics:
Conductor Size:2 Conductors / 1 Pair
Conductor Stranding: Tinned Copper
Insulation Material & Color: PVC Black & White
Rip Cord: Optional
Jacket Material: FR-Retardant PVC
Jacket Color: Grey
|
Part No.
|
Conductor
|
Stranding
|
Insulation Color
|
Insulation
Thickness |
|
Jacket
O.D(Nom) |
|
Jacket
Thickness |
|
|||
|
|
|
|
|
inch
|
mm
|
inch
|
mm
|
inch
|
mm
|
|||
|
#8471
|
16AWG
|
19x29AWG
(0.28mm) |
Black & White
|
0.023
|
0.58
|
0.274
|
6.96
|
0.032
|
0.81
|
|||
|
#8473
|
14AWG
|
42x30AWG
(0.254mm) |
Black & White
|
0.031
|
0.79
|
0.340
|
8.64
|
0.032
|
0.81
|
|||
|
#8477
|
12AWG
|
64x30AWG
(0.254mm) |
Black & White
|
0.032
|
0.81
|
0.386
|
9.80
|
0.035
|
0.89
|
|||
|
Part No.
|
Conductor
DCR(Nom.) |
Capacitance Conductor to Conductor(Nom.)
|
Inductance
(Nom.) |
Voltage
|
Current (Max. Recommended A@25ºC)
|
|
#8471
|
4.49Ω/1000ft
(14.72Ω/km) |
33pF/ft
(108.2pF/m) |
0.19μH/ft
(0.62μH/m) |
300V
|
6.1A
|
|
#8473
|
2.86Ω/1000ft
(9.38Ω/km) |
22F/ft
(72pF/m) |
0.19μH/ft
(0.62μH/m) |
300V
|
9.6A
|
|
#8477
|
1.8Ω/1000ft
(5.9Ω/km) |
15pF/ft
(49.2pF/m) |
0.18μH/ft
(0.59μH/m) |
300/600V
|
13A
|
Environmental Properties:
Breakdown Voltage(Nom.): Jacket 20KV RMS
Breakdown Voltage Between Conductors(Nom.): 20KV RMS
Installation: 0 to +60 ºC
Storage & Operation: -20 to +75 ºCEnvironmental Properties:
Breakdown Voltage(Nom.): Jacket 20KV RMS
Breakdown Voltage Between Conductors(Nom.): 20KV RMS
Installation: 0 to +60 ºCStorage & Operation: -20 to +75 ºC
Certifications & Approval:
ISO9001, ISO14001, OHSAS18001
UL 13, UL444,
UL,CUL/ETL Listed Type: CMG CL3R FT4 (UL 1666/UL1685)
RoHS / REACH Compliant
CPR Class: Eca/ IEC60332-1-2
Certifications & Approval:
ISO9001, ISO14001, OHSAS18001
UL 13, UL444,
UL,CUL/ETL Listed Type: CMG CL3R FT4 (UL 1666/UL1685)
RoHS / REACH Compliant
CPR Class: Eca/ IEC60332-1-2
Breakdown Voltage(Nom.): Jacket 20KV RMS
Breakdown Voltage Between Conductors(Nom.): 20KV RMS
Installation: 0 to +60 ºC
Storage & Operation: -20 to +75 ºCEnvironmental Properties:
Breakdown Voltage(Nom.): Jacket 20KV RMS
Breakdown Voltage Between Conductors(Nom.): 20KV RMS
Installation: 0 to +60 ºCStorage & Operation: -20 to +75 ºC
Certifications & Approval:
ISO9001, ISO14001, OHSAS18001
UL 13, UL444,
UL,CUL/ETL Listed Type: CMG CL3R FT4 (UL 1666/UL1685)
RoHS / REACH Compliant
CPR Class: Eca/ IEC60332-1-2
Certifications & Approval:
ISO9001, ISO14001, OHSAS18001
UL 13, UL444,
UL,CUL/ETL Listed Type: CMG CL3R FT4 (UL 1666/UL1685)
RoHS / REACH Compliant
CPR Class: Eca/ IEC60332-1-2
Certification
Exhibition
FAQ
1. What's your company MOQ?
- Our MOQ is 30km. But MOQ of stocks are 1 pcs.
2. Can you do our design?
- Of course, your customized design (OEM) is available.
3. What's the lead-time for order delivery?
- Within 10~30days.
4. Can you send a sample for us?
- Yes, we can provide free samples.
5. What is your packaging?
- Our packaging includes PE film, shrink bag, pull box, paper reel, plastic reel, wooden reel. Depends on what you want!
6. Delivery time and transportation method?
- Shipment can be arranged immediately. By express, by sea, by air, you can ship whatever you want.
7.Payment method?
- T/T, L/C, we also accept most other convenient methods of payment.
- Our MOQ is 30km. But MOQ of stocks are 1 pcs.
2. Can you do our design?
- Of course, your customized design (OEM) is available.
3. What's the lead-time for order delivery?
- Within 10~30days.
4. Can you send a sample for us?
- Yes, we can provide free samples.
5. What is your packaging?
- Our packaging includes PE film, shrink bag, pull box, paper reel, plastic reel, wooden reel. Depends on what you want!
6. Delivery time and transportation method?
- Shipment can be arranged immediately. By express, by sea, by air, you can ship whatever you want.
7.Payment method?
- T/T, L/C, we also accept most other convenient methods of payment.
