Quick Details
-
Max. Forward Voltage:
-
1.0
-
Max. Reverse Voltage:
-
50-1000V
-
Max. Forward Current:
-
1A
-
Max. Reverse Current:
-
5uA
-
part number:
-
LL4007 MELF Rectifier Diod 1N4007 SMD
-
current:
-
1A
-
voltage:
-
1000V
-
package:
-
MELF
-
packing:
-
tape in reel
-
SPQ:
-
5000pcs
-
peak forward sugar current:
-
30A
-
VF:
-
1.1V
-
Operating temperature range:
-
-65°c - +150°c
-
Storage temperature range:
-
-65°c - +150°c
Quick Details
-
Model Number:
-
Diod 1N4007 SMD
-
Brand Name:
-
XUYANG
-
Place of Origin:
-
Jiangsu, China
-
Max. Forward Voltage:
-
1.0
-
Max. Reverse Voltage:
-
50-1000V
-
Max. Forward Current:
-
1A
-
Max. Reverse Current:
-
5uA
-
part number:
-
LL4007 MELF Rectifier Diod 1N4007 SMD
-
current:
-
1A
-
voltage:
-
1000V
-
package:
-
MELF
-
packing:
-
tape in reel
-
SPQ:
-
5000pcs
-
peak forward sugar current:
-
30A
-
VF:
-
1.1V
-
Operating temperature range:
-
-65°c - +150°c
-
Storage temperature range:
-
-65°c - +150°c
Product Introduction
With strong R&D capabilities,advanced production equipment and perfect measurement devices,
we supply qualified products and service in accordance with ISO9001 quality management system.
All products have passed hazardous substance test,met standards of EU and USA.
And we are confident we can meet your OEM/ODM requirements.
|
Name |
SMD Rectifier Diode |
|
Part Number |
LL4007,1N4007 |
|
Current |
1A |
|
Voltage |
1000V |
|
Package |
MELF |
|
Packing |
tape in reel |
|
SPQ |
5000pcs |
|
Original |
CHINA |
|
H.S Code |
85411000 |
-
Features:
- Glass passivated junction
- Low current leakage
- Metalurgically bonded construction
- Surface Mount application
-
Maximum rating:
- Operating temperature: -65 to +150°C
- Storage temperature: -65 to +150°C
- Maximum thermal resistance, 30°C/W junction to lead
Packing & Shipping
We can ship by DHL/FedEx/UPS/TNT/EMS, by air or by sea.
We will recommend the most suitable shipping method based on your order quantity.
