Quick Details
-
Power:
-
15.5KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
newindu
-
Maximum Digging Height:
-
3200mm
-
Maximum Digging Depth:
-
2100mm
-
Machine Weight:
-
13500 kg
-
Max Digging Radius:
-
3530mm
-
Rated Speed:
-
2.9km/h
-
Single gross weight:
-
1825kg
-
Single package size:
-
974X258X319 cm
-
Bucket capacity (m3):
-
0.05m3
-
Certification:
-
ISO CE
-
Dimension(Long * Breadth * High):
-
6146 *2588 *2210 mm
Quick Details
-
Operating Weight:
-
6TON
-
Bucket capacity:
-
1.2M³
-
Engine Brand:
-
Other
-
Power:
-
15.5KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
newindu
-
Maximum Digging Height:
-
3200mm
-
Maximum Digging Depth:
-
2100mm
-
Machine Weight:
-
13500 kg
-
Max Digging Radius:
-
3530mm
-
Rated Speed:
-
2.9km/h
-
Single gross weight:
-
1825kg
-
Single package size:
-
974X258X319 cm
-
Bucket capacity (m3):
-
0.05m3
-
Certification:
-
ISO CE
-
Dimension(Long * Breadth * High):
-
6146 *2588 *2210 mm
Newindu Mini Excavator Spare Parts SE135
Ace products, super cost-effective
The SE135-9 hydraulic excavator is a master of Shantui excavator product technology. It is energy-efficient, durable and provides customers with a better experience. The world-class hydraulic system is used, and the self-developed electronic control system is equipped with faster speed, lower fuel consumption and more sensitive action. The newly designed large cab has a spacious front and rear space for the driver, and a large curvature mirror on the outside. The work field is wide and the work is safe and reliable.
High-end system configuration
International leading high adaptive turbocharged engine
World-class hydraulic configuration, high working pressure and low pressure loss
Enhanced working device
Comprehensively optimize the structural design, strengthen the key position of the force, no fear of bad conditions
The bucket bottom plate, side plate and reinforcing plate are made of high-strength wear-resistant material to improve the durability of the bucket.
Multi-size boom, stick and bucket are easily combined to adapt to various working conditions
Four rounds
30 years of four-wheel development and manufacturing experience, the world's leading technology
The world's top forging heat treatment process, the quality is stable and reliable
Intelligent electronic control, optimal power control
Intelligent control system for optimal matching of power system and hydraulic system, improving work efficiency and reducing fuel consumption
A new generation of intelligent electronic control system that makes your machine work.
Preset P (reload mode), E (economy mode), A (auto mode), B (breaker mode) four working modes, easy to switch
Through the cloud platform, you can view the location, running track, working status and other related information of the vehicle at any time.
Spacious and comfortable operating environment
Injection molding interior, effective matching of interior colors according to ergonomics, not easy to cause operator's visual fatigue
Large space, wide field of view, reasonable layout of operating devices, convenient and comfortable operation
High-power air conditioning, suspension seat, comfortable ride
Fast and convenient maintenance
The double-cylinder support and the hood that opens rearward are light and easy to maintain.
Electrical components are arranged centrally for easy inspection and maintenance
Coolant filling, air filter replacement, power main switch at your fingertips
The fuel filter, oil filter and pilot filter are arranged centrally, and all maintenance and replacement can be completed in the same position.
High-precision fuel filter with large water capacity, strong fuel adaptability, self-contained electric oil pump, automatic oil replenishment, easy to start
Machine optional configuration
Oil bath air prefilter
Cab warning light
Rear camera
Cab top protection net
Protective net in front of the cab
Front under guard net
600mm track shoe narrow bucket
Multi-function device selection table:
Optional accessory
Breaker
Ripper
Wood grab
Hydraulic
Stone grab
Quick change device
|
Dimensions |
SE135-9 |
|
Total length (mm) |
7860 |
|
Grounding length (during transportation) (mm) |
4320 |
|
Total height (to the top of the boom) (mm) |
2800 |
|
Total width (mm) |
2500 |
|
Total height (to the top of the cab) (mm) |
2855 |
|
Counterweight ground clearance (mm) |
915 |
|
Minimum ground clearance (mm) |
425 |
|
Tail radius of gyration (mm) |
2380 |
|
Track length (mm) |
3645 |
|
Gauge (mm) |
2000 |
|
Track width (mm) |
2500 |
|
Track shoe width (mm) |
500 |
|
Slewing platform width (mm) |
2490 |
|
Distance from the center of rotation to the rear end (mm) |
2375 |
|
The scope of work |
|
|
Maximum excavation height (mm) |
8495 |
|
Maximum unloading height (mm) |
6060 |
|
Maximum excavation depth (mm) |
5490 |
|
Maximum vertical excavation depth (mm) |
4625 |
|
Maximum excavation distance (mm) |
8300 |
|
Maximum digging distance of ground plane (mm) |
8175 |
|
Working device minimum radius of gyration (mm) |
2445 |
|
engine |
|
|
model |
QSF3.8T |
|
form |
Water-cooled 4-cylinder in-line turbocharger |
|
Displacement (L) |
3.76 |
|
Rated power (kw/rpm) |
86/2200 |
|
Hydraulic system |
|
|
Hydraulic pump form |
Variable double piston pump |
|
Rated working flow (L/min) |
2x130 |
|
Bucket |
|
|
Bucket capacity (m3) |
0.4~0.65 (0.55) |
|
Slewing system |
|
|
Maximum turning speed (r/min) |
11.3 |
|
Brake type |
Pressure release mechanical brake |
|
Digging force |
|
|
Stick digging force (KN) |
70 |
|
Bucket digging force (KN) |
97 |
|
Operating weight and ground pressure |
|
|
Operating weight (Kg) |
13500 |
|
Ground specific pressure (KPa) |
41.5 |
|
Walking system |
|
|
Travel motor |
Axial variable piston motor |
|
Walking speed (km/h) |
3.25/5.2 |
|
Traction (KN) |
118 |
|
Gradeability |
70% (35°) |
|
Oil capacity |
|
|
Fuel tank capacity (L) |
220 |
|
Cooling system (L) |
20 |
|
Engine oil quantity (L) |
12 |
|
Hydraulic tank / system capacity (L) |
177/205 |
