- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
JRX
-
Model Number:
-
JMM1525-BY0716QT009050L37
-
Torque:
-
Requests
-
Rated Current:
-
60mA Max
-
Rated Volage:
-
1.5V DC
-
Stall Current:
-
1A Max
-
Diameter:
-
7mm
-
Shaft diameter:
-
1.0mm
-
Motor type:
-
lead wire
-
Size:
-
7*16(mm)
-
Application:
-
Long Life Time Low Noise Motor for mini helicopter motor
-
Free sample:
-
Available
-
Customized:
-
Yes
Quick Details
-
Speed(RPM):
-
25000 ± 2000 rpm
-
Continuous Current(A):
-
60mA Max
-
Efficiency:
-
IE 2
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
JRX
-
Model Number:
-
JMM1525-BY0716QT009050L37
-
Torque:
-
Requests
-
Rated Current:
-
60mA Max
-
Rated Volage:
-
1.5V DC
-
Stall Current:
-
1A Max
-
Diameter:
-
7mm
-
Shaft diameter:
-
1.0mm
-
Motor type:
-
lead wire
-
Size:
-
7*16(mm)
-
Application:
-
Long Life Time Low Noise Motor for mini helicopter motor
-
Free sample:
-
Available
-
Customized:
-
Yes
Product Application
Best Quality for 1.5V DC Micro Motor (
JMM1525-BY0716QT009050L37
) is widely used for RC Toys, RC Car, RC Helicopter, Quadrocopter, Aeromodelling, Health protection equipment,Electric Toys, Toy Car, Toy Boat, Model Train, Toy Airplane, Dental equipment,Electric Shaver, Small Electric Fan, CPU Cooler Fan, Game Machine, Game Handle, Game Controller, etc.
|
SPECIFICATIONS FOR BEST QUALITY FOR 1.5V DC MICRO MOTOR
(JMM1525-BY0716QT009050L37)
|
|
|
|
|||
|
Model Size
|
Shaft diameter
|
mm
|
1.0
|
|||
|
|
Motor diameter
|
mm
|
7.0
|
|||
|
|
Body length
|
mm
|
16.0
|
|||
|
Main performance parameters
|
Rated voltage
|
V
|
1.5
|
|||
|
|
Speed (max. & min.)
|
r/min
|
25000+_2000
|
|||
|
|
Rated current
|
mA
|
15
|
|||
|
Customize parts
|
Shaft length /Diameter
|
mm
|
0.8/1.0
|
|||
|
|
Wire length/Colour
|
mm/Red,Black,White
|
Customised
|
|||
|
|
Rotation
|
CW/CCW
|
CW/CCW
|
|||
Main Features
1) Energy-saving:High energy conversion efficiency,more than 70%.
2) Reliable Operational Stability: Operates quietly and quickly with high efficiency and low resistance.
3) Low Noise : Starting and braking quietly, running with low noise.
4) High Speed : The rpm can reach 4500~51000±10%.
5) Fast Response:Rapid starting and braking with fast response, mechanincal time constant is less than 28 milliseconds. Some can reach 10ms or less.
|
Packaging For Samples
|
|
|
|
Size
|
175(L) * 95(W) * 75(H)(MM)
|
|
|
Weight
|
0.5KG
|
|
|
Packaging Details
|
The normal package is foam box(Size: 175L*95W*75H), inner use plastic bag or pack it according to customers special request.
|
|
|
Packaging For Quantity
|
|
|
|
Size
|
510 (L) * 300 (W) * 300 (H)
|
|
|
Weight
|
9.5KG
|
|
|
Packaging Details
|
The normal package is carton box(Size: 500L*300W*300H). Inner use plastic tray (Size:205L*165W*5H),or pack it according to customers special request.
|
|
Q: Is there a MOQ for your motors?
A: Yes. The MOQ is 1,000pcs for different models after sample approval. But it's also okay for us to accept smaller lots like a few dozens, hundreds after sample approval.
Q: Could you send me a price list?
A: For all of our motors, they are customized based on different requirements like lifetime, noise, voltage, and shaft etc. The price also varies according to annual quantity. So it's really difficult for us to provide a price list. If you can share your detailed requirements and annual quantity, we'll see what offer we can provide.
Q: Is it possible for you to develop new motors if we provide the tooling cost?
A: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we'll make our evaluation to see if we can arrange or not .
