Quick Details
-
Power:
-
15-70Kw depends on size
-
Weight:
-
1500 KG
-
Dimension(L*W*H):
-
910mmx910mmx2200mm
-
Processing Types:
-
Alcohol
-
Material:
-
SUS304/SUS316/red Copper
-
Product name:
-
brewery equipment
-
Application:
-
Wine Whiskey Vodca Gin Tequila Brandy
-
Capacity:
-
20HL
-
Heating:
-
Electrical Steam Heatig
-
Cleaning:
-
CIP System
-
Color:
-
Silver
-
Control System:
-
Semi-automatic
-
Package:
-
Plywoodcases
-
Surface Treatment:
-
Polished
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Tiantai or OEM
-
Voltage:
-
3phase/380v/50 (60)Hz
-
Power:
-
15-70Kw depends on size
-
Weight:
-
1500 KG
-
Dimension(L*W*H):
-
910mmx910mmx2200mm
-
Processing Types:
-
Alcohol
-
Material:
-
SUS304/SUS316/red Copper
-
Product name:
-
brewery equipment
-
Application:
-
Wine Whiskey Vodca Gin Tequila Brandy
-
Capacity:
-
20HL
-
Heating:
-
Electrical Steam Heatig
-
Cleaning:
-
CIP System
-
Color:
-
Silver
-
Control System:
-
Semi-automatic
-
Package:
-
Plywoodcases
-
Surface Treatment:
-
Polished
2000L 20HL SUS304 Stainless steel steam heating 2 vessel beer plant machinery for sale
2000L 20HL SUS304 Stainless steel steam heating 2 vessel beer plant machinery is often used in small breweries or bars. The system consists of two brewhouse vessels---Mash/Lauter Tun and Kettle/Whirlpool Tun. Mashing and lauter process are worked in one tank, and the kettle and whirlpool process are worked in one tank,this configuration can save brewery cost and floor space.
This system usually brews one batch per day. If the second batch is required,it will need at least 14 hours more. This system can cope with a temporary increase in production but not suitable for planned multi-batch brewing.
According to different fermentation time, usually 6 sets of 4 000L fermenters or 12 sets of 20 00L fermenters can be configured. 4 sets of 4 000L fermenters and 4 sets of 20 00L fermenters can also be configured to meet the needs of various beer types.
This brewery system also needs to be equipped with a complete automatic or manual control system, malt milling system, CIP system,glycol cooling system, steam heating system, air system, etc.
1) Passed ISO TUV SGS production process inspection, Tiantai beer equipment meets the GB CE PED ASME standard
2) Five years guarantee for a long time sales service
3) Local service in EUROPE, AUSTRALIA ETC
4) 0 trade risk verified by more than 1100 breweries
5) D irect food grade c ompletely certificated 304 stainless steel
1) Passed ISO TUV SGS production process inspection, Tiantai beer equipment meets the GB CE PED ASME standard
2) Five years guarantee for a long time sales service
3) Local service in EUROPE, AUSTRALIA ETC
4) 0 trade risk verified by more than 1100 breweries
5) D irect food grade c ompletely certificated 304 stainless steel
1) Two vessels with hot water tank, 20 00L per batch, the first batch takes about 8 hours, and two batches in 14 hours is allowed ;
2) Completely SUS304 stainless steel material, easy to clean; Red copper outside can also be used to adapt to special environments such as bars;
3) Steam heating and kettle process can get high thermal efficiency and there is no taste effect on wort;
4) The wort is cooled by city water and -5 degrees glycol water in two stages, and it can also be designed to cool in a single stage;
5) Brewhouse heating temperature and fermentation cooling temperature are automatically controlled, manual control can be switched at any time;
6) Manual valve control, humanized operation, low investment, high cost performance; PLC automatic control can be optional;
7) Filling system can fill stainless steel beer barrels, glass bottles or cans
|
Part 1: 5 00- 8 00kg/hr Malt Milling Unit |
||
|
|
5 00- 8 00kg/hr Malt Miller |
1set |
|
|
Flexible Auger |
1set |
|
|
Milling Controling Cabinet |
1set |
|
Part 2: 20 00L Two Vessel/HLT Brewhouse |
||
|
|
20 HL Mash/Lauter Tun |
1set |
|
|
20 HL Kettle/Whirlpool Tun |
1set |
|
|
4 0HL Hot Water Tank |
1set |
|
Part 3: Fermentation Unit |
||
|
|
4 000L Fermentation Tank/Unitank |
4 sets |
|
|
20 00L Fermentation Tank/Unitank |
4 sets |
|
|
4 000L Bright Beer Tank |
1 set |
|
|
4 000L Bright Beer Tank |
1 set |
|
Part 4: Glycol Cooling Unit |
||
|
|
4 000L Glycol Water Tank |
1set |
|
|
8 HP Glycol Water Chiller |
2sets |
|
|
Glycol Water Pipeline |
1unit |
|
Part 5: Electric Control Unit |
||
|
|
Brewhouse Control Cabinet |
1set |
|
|
Fermentation Control Cabinet |
1set |
|
Part 6: 2 00L Portable CIP Cart [Two Tanks] |
||
|
|
2 00L Single Wall Caustic Tank |
1set |
|
|
2 00L Single Wall Acid Tank |
1set |
|
|
Sanitary Centrifugal Pump |
1set |
|
Part 8: Keg Filling Unit |
||
|
|
1-Station Keg Filler |
1set |
|
|
2-Station 2-Tank Auto Keg Rinser |
1set |
|
Part 9: Bottle Filling Unit |
||
|
|
Automatic Bottling Line [8-6-1 heads] |
1set |
