One xDSL(RJ11) interface,
Four Fast Ethernet LAN(RJ45) interfaces;
1*USB2.0 Port
1*USB2.0 Port
- Product Details
- {{item.text}}
Quick Details
-
2.4G Wi-Fi Transmission Rate:
-
300 Mbps
-
Type:
-
Wireless
-
Brand Name:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
wifi router 1200mbps
-
Chipset:
-
Triductor VSPM300
-
Antenna:
-
4*5 DBi External Antenna
-
Wireless Speed:
-
1200Mbps
-
Color:
-
Black
-
Interface:
-
RJ45*5+ +Reset/WPS button*1+ WLAN Switch*1+ Power jack*1
-
Warranty:
-
1 year
-
RF Power(2.4G):
-
23.5dbm
-
RF Power(5G):
-
22dbm
-
Certification:
-
ce,RoHS
Quick Details
-
Max. LAN Data Rate:
-
867Mbps
-
With Modem Function:
-
Yes
-
Wi-Fi Supported Frequency:
-
2.4G & 5G
-
2.4G Wi-Fi Transmission Rate:
-
300 Mbps
-
Type:
-
Wireless
-
Brand Name:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
wifi router 1200mbps
-
Chipset:
-
Triductor VSPM300
-
Antenna:
-
4*5 DBi External Antenna
-
Wireless Speed:
-
1200Mbps
-
Color:
-
Black
-
Interface:
-
RJ45*5+ +Reset/WPS button*1+ WLAN Switch*1+ Power jack*1
-
Warranty:
-
1 year
-
RF Power(2.4G):
-
23.5dbm
-
RF Power(5G):
-
22dbm
-
Certification:
-
ce,RoHS
Product Description
1200mbps transmission
Beamforming technology
concentrat the data transmission;
Support 802.11ac
compatible with 802.11b/g/n devices
More ports
to choose
|
Product Name
|
gigabit router
|
|
Interface
|
1x10/100Mbps WAN port, 4x10/100Mbps LAN ports;
1*USB2.0 Port |
|
Button
|
Quick Setup Security Button (WPS Compatible)
Reset button (Press in 10 seconds: reset to default settings) |
|
Data Rate
|
1200Mbps
|
|
Modulation
|
OFDM = BPSK,QPSK,16-QAM,64-QAM;
DSSS = DBPSK,DQPSK,CCK |
|
Antenna
|
four 5dBi high-gain omni antennas
|
|
Frequency
|
2.4GHz: 2400MHz-2484MHz
5.8GHz: 5180MHz~5825MHz |
|
Operation Mode
|
Gateway, Wi-Fi Repeater, Wireless AP
|
|
LED Indicatore
|
PWR(Power), WAN, LAN, NET(Ethernet)
|
|
EVW
|
2.4G: 802.11b: ≤-10dB; 802.11g: ≤-25dB ; 802.11n: ≤-28dB
5G: 802.11a: ≤-25dB; 802.11n: ≤-28dB; 802.11ac: ≤-32dB |
|
Wireless Functions
|
beamforming technology
|
|
Wireless Security
|
64/128/152-bit WPA/WPA2/TKIP/AES
|
|
WAN Type
|
Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
|
|
DHCP
|
DynDns, Comexe, NO-IP
|
|
Quality of Service
|
WPA-PSK/ WPA2-PSK encryption
|
|
Port Forwarding
|
Virtual Server,Port Triggering, UPnP, DMZ
|
|
Dynamic DNS
|
DynDns, NO-IP
|
|
Access Control
|
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
|
|
Firewall Security
|
DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding |
|
Environment
|
Working Temperature: -30°C to 55°C
Storage Temperature: -40°C to 70°C Humidity：5％～95％（Non-condensing） |
|
|
|
Related Products
FAQ
Q1.How can I get product Price List?
A1:Contact us by email,TradeManager,Skype or sent inquiry to us.
Q2, Can I get samples to test before place an order?
A2: Yes . Samples are available ,and the sample cost is refundable .
Q3: How does your factory do regarding quality control?
A3: Quality is the priority.
All products will produced strictly according to CE,FCC,ROSHregulations.
Q4: What's the best way for shipping?
A4: DHL for small order. Air cargo&Sea shipment for big quantity order.
Q5: Can we get support if we want a special outlook and function addition ?
A5: No problem ! Our R&D team will support you develop a new kind and best solution for you !
Q6: What is the warranty for your products?
A6: 12 Months
A1:Contact us by email,TradeManager,Skype or sent inquiry to us.
Q2, Can I get samples to test before place an order?
A2: Yes . Samples are available ,and the sample cost is refundable .
Q3: How does your factory do regarding quality control?
A3: Quality is the priority.
All products will produced strictly according to CE,FCC,ROSHregulations.
Q4: What's the best way for shipping?
A4: DHL for small order. Air cargo&Sea shipment for big quantity order.
Q5: Can we get support if we want a special outlook and function addition ?
A5: No problem ! Our R&D team will support you develop a new kind and best solution for you !
Q6: What is the warranty for your products?
A6: 12 Months
