Quick Details
-
Color:
-
Red
-
Motor:
-
9kw Motor
-
Brand:
-
Zhongyi
-
Battery:
-
6V230AH
-
Type:
-
Sightseeing Car
-
Dimension:
-
4380*1500*2070 mm
-
Max. Speed:
-
28km/h
-
Controller:
-
72V
-
Charging Time:
-
8-10hours
Quick Details
-
Brand Name:
-
Zhongyi
-
Place of Origin:
-
Tianjin, China
-
Seats:
-
17
-
Color:
-
Red
-
Motor:
-
9kw Motor
-
Brand:
-
Zhongyi
-
Battery:
-
6V230AH
-
Type:
-
Sightseeing Car
-
Dimension:
-
4380*1500*2070 mm
-
Max. Speed:
-
28km/h
-
Controller:
-
72V
-
Charging Time:
-
8-10hours
|
Model |
GD 17 -A 17 + F |
|
Qty/40′( assembled) |
1 Units |
|
Performance |
|
|
Passenger Capacity |
1 7 Seats |
|
Max.Speed |
28-30km/h(adjustable) |
|
Range |
110-120 km |
|
Climbing Ability |
<20% |
|
Braking Distance |
<5m |
|
Mini Turning Radius |
8 . 2 m |
|
Min.Ground Clearance |
130mm |
|
Recharge Time |
8-10hours |
|
Dimension |
|
|
L*W*H |
6050*1500*2080 mm |
|
F/R Tread |
1240/1220mm |
|
Axle Distance |
3665 mm |
|
Net Weight |
11 6 0kgs |
|
Standard Configuration |
|
|
Motor |
72V/ 5. 5 KW DC motor |
|
Controller |
USA Crutis Controller |
|
Battery |
Huge capacity deep cycle lead-acid battery 6V/piece 12 pieces 2 3 0Ah |
|
Body & Roof |
Injection molding modeling design separable replacement with all aluminum frame |
|
Windshield |
Laminated Glass with wiper |
|
Seats |
Sponge& artificial Leather ,the seaters of driver and co-driver are adjustable |
|
Rear View Mirror |
2 pcs |
|
Tire |
Aluminum alloy hub ,155R12C |
|
Chassis |
High strength structural steel |
|
Steering |
Gear steering & auto backlash compensation & electronic power steering |
|
Braking System |
Front disk & rear drum , double circuit hydraulic brake & hand brake |
|
Front Axle |
Mcpherson independent suspension Spiral spring & cylinder hydraulic shock absor ption |
|
Rear Axle |
Integral rear axle, Non independent suspension, leaf spring & cylinder hydraulic shock absor ption |
|
Lighting System |
Combination LED front light (turning light, high beam, dipped light) rear light (turning light, brake light) driving & reverse buzzer. |
|
Charger |
On board charger |
|
Dashboard |
Plastic molding instrument board with volt meter, ammeter, electricity indicator , speedometer ,key switch, radi o, USB plug, storage box , cup holder |
|
Removable door |
12 t emper ed glass doors and 1 rear glass |
