Quick Details
-
Injection Rate (g/s):
-
40 g/s
-
Injection Weight (g):
-
65 g
-
Screw Speed (rpm):
-
0 - 230 rpm
-
Screw diameter (mm):
-
26 mm
-
Weight (KG):
-
950 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
175 mm
-
Model Number:
-
XCX-200STK
-
Brand Name:
-
XCX
-
Power (kW):
-
4 kW
-
Single package size::
-
1.35*0.85*2.5M
-
Single gross weight:
-
950KG
-
Screw diameter:
-
26/28
-
Injection pressure:
-
1920g/cm2
-
Max shot weight (PS):
-
55/65
-
Clamping force:
-
20t
-
Opening stroke:
-
175mm
-
Weight (after packing):
-
950
-
Marketing Type:
-
Ordinary Product
Quick Details
-
Ejector Stroke(mm):
-
170 mm
-
Ejector Force(kN):
-
2000 kN
-
Theoretical Shot Volume(cm³):
-
23 cm³
-
Injection Rate (g/s):
-
40 g/s
-
Injection Weight (g):
-
65 g
-
Screw Speed (rpm):
-
0 - 230 rpm
-
Screw diameter (mm):
-
26 mm
-
Weight (KG):
-
950 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
175 mm
-
Model Number:
-
XCX-200STK
-
Brand Name:
-
XCX
-
Power (kW):
-
4 kW
-
Single package size::
-
1.35*0.85*2.5M
-
Single gross weight:
-
950KG
-
Screw diameter:
-
26/28
-
Injection pressure:
-
1920g/cm2
-
Max shot weight (PS):
-
55/65
-
Clamping force:
-
20t
-
Opening stroke:
-
175mm
-
Weight (after packing):
-
950
-
Marketing Type:
-
Ordinary Product
Product Description
FEATURES
1.Two/ there section the temperature control/ projects the speed/back pressure, not to have the section adjustment suits components of the precise plastic to take shape
2.The fast lock mold/ low pressure idling speed closes the mold, locks the mold exceptionally when the automatic tight open the mold
3.The end products have the fluid capping to leave the installment, the end product takes out extremely facilitates easily
4.May supplement add mold 1S with double slippery mold 2S. Lets the operator more convenient production efficiency and safe
Sample Display
Details Images
The temperature control of the second (third) stage, the firing rate, the pressure, and the screw speed are infinitely adjustable, precise and stable.
Fast mold clamping, reducing pressure and mold clamping, and protecting the safety of mold life
Single and double slides can be installed, which is more convenient to operate and higher safety.
Regarding our spot, the stock is sufficient. Fast delivery
