TTL55 line array dual 12 inch three way line array speaker ,double 12 inch line array active with amplifier module ,it is very suitable for big show ,big concert ,it can cover over 5000 people show
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
TTL55
-
Product Name:
-
TTL55
-
Type:
-
3-way Line Array
-
Application:
-
Concert
-
Power:
-
3600W
-
Color:
-
Black
-
Use:
-
Karaoke Player
-
Material:
-
Plywood
-
Frequency response:
-
45Hz-500Hz
-
Size:
-
421*548*1087mm
-
Certification:
-
FCC
Quick Details
-
Warranty:
-
3years
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ACTPRO
-
Model Number:
-
TTL55
-
Product Name:
-
TTL55
-
Type:
-
3-way Line Array
-
Application:
-
Concert
-
Power:
-
3600W
-
Color:
-
Black
-
Use:
-
Karaoke Player
-
Material:
-
Plywood
-
Frequency response:
-
45Hz-500Hz
-
Size:
-
421*548*1087mm
-
Certification:
-
FCC
Product Description
|
Product Name
|
Model: TTL-55A
|
|
Package
|
carton or flight case
|
|
Impedance
|
LF:16Ω MF:16Ω HF:16Ω
|
|
Frequency Response:
|
LF:45Hz-500Hz MF:500Hz-2.2KHz HF:2.2K-20KHZ
|
|
Average power:
|
L:900W M:200W H:180W
|
|
Peak power:
|
L:3600W M:800W H:640W
|
|
Sensitivity：
|
L:98dB/w/m M:97dB/w/m H:114 dB/w/m
|
|
Component：
|
2×12+ 10 +3x2"
|
|
Cabinet :
|
Birch Multilayer Plywood
|
|
Dispersion：
|
100°Hx10°V
|
|
MAX.SPL:
|
L:128dB M:117dB H:137 dB
|
|
Input Interface：
|
2XNL8MPR Speakon, 2 X XLR(M)+2 X XLR(F)
|
|
Amplifier Module：
|
Built-in DSP/3 channels 2 in 3 out
|
|
AMP Output Power:
|
2×600W+1100w/8 ohm
|
|
Channel:
|
3 channels
|
|
Output Circuit Design:
|
Class D
|
|
Built -in DSP module:
|
2 in 3 out
|
|
Product（HWD）:
|
377(310)×550×1020mm
|
|
Packing WHD:
|
421×548×1087mm
|
-
Product performance description
-
Related Products
Packing&Shipping
carton or flight case
Company Introduction
Guangzhou Actpro Audio Co.Ltd, was established in 2010, located in Guangzhou,China, is a collection of industry and trade as a whole has the right of import and export professional foreign trade company .
Our company is specialized in professional speakers , engage in producing column speaker,line array system ,subwoofer,power amplifier and so on.
FAQ
1. Q: Are you manufacturer or trade company?
A: We are the manufacturer, specialized in producing column speaker,line array system ,active subwoofer,power amplifier and so on.
2. Q: How can I get the samples?
A: We appreciate that you can accept to pay the sample fee and the sample freight.
3. Q: How much the transportation freight of samples?
A: The freight depends on the weight and packing size in your area.
4. Q: What's the delivery time for the samples?
A: The samples will be ready for delivery in 5-10days after we receive your payment.
5. Q: Do you offer OEM&ODM service?
A: Yes, we do offer OEM&ODM service.
6. Q: How do your factory control quality?
A: Quality is the most important for us. In order to control quality better, we have professional QC.
All our products pass 4 times inspection by QC before delivery. The first time for raw material, second time for finished products, third time for products appearance and fourth time for function.
