Quick Details
-
Application:
-
Office Building
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XSC, SUNVISION, NEW VISION, ALILULA,3M
-
Model Number:
-
PDLC
-
Product Name:
-
PDLC Smart Film
-
Material:
-
PET material
-
style:
-
luxury
-
Adhesive:
-
Self adhesive
-
MOQ:
-
1 Roll
-
Color:
-
Clear,White
-
Packing:
-
Carton
Quick Details
-
Warranty:
-
3 years
-
After-sale Service:
-
Online technical support, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects
-
Application:
-
Office Building
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XSC, SUNVISION, NEW VISION, ALILULA,3M
-
Model Number:
-
PDLC
-
Product Name:
-
PDLC Smart Film
-
Material:
-
PET material
-
style:
-
luxury
-
Adhesive:
-
Self adhesive
-
MOQ:
-
1 Roll
-
Color:
-
Clear,White
-
Packing:
-
Carton
Products Description
PDLC film is the abbreviation of Polymer Dispersed Liquid Crystals film which is basically
three-dimensional structures composed by liquid crystal microdrops dispersed in a polymer
matrix. Polymer-dispersed liquid crystal (PDLC) films are useful in light control
applications because they can be switched electrically between light scattering and
transparent states.
Flexible PET film with conductive material coated by high –tech manufacturing facility
name “smart web” named ITO film, the percentage of conductive material and PET film
quality is key factor make PDLC film of good quality outstanding with high transmittance,
resistance to high voltage shocks. The liquid crystal is sandwiched between the 2 ITO film
by lamination machine, this is how the PDLC film is made.
|
Appearance
|
Translucent (Power off)/Transparent (Power on)
|
|
|
||
|
Color Options
|
Clear, Light Blue, Milky, Red, Yellow, Black & More
|
Haze (On)
|
< 3.0%
|
||
|
Thickness
|
120 μm (micrometers)
|
Transparency (On)
|
> 83.0%
|
||
|
Sheet Size
|
White (Power off)/Crystal (Power on)
|
Visible Light Reflection Rate
|
< 1.5%
|
||
|
Driving Voltage
|
60±10 V (AC, 50/60Hz, less than 3.28 ft x 8.20 ft)
|
Viewing Angle
|
> 160° at Clear Stage
360°C Viewable for Projection Viewing Angle |
||
|
Current
|
0.20 (A/m2)
|
Operation Temperature Range
|
-13°F to 149°F
|
||
|
Energy Consumption
|
.00077 (W/in2)
|
Storage Temperature Range
|
-58°F to 158°F
|
||
|
Response Time
|
< 0.05 sec
Powering On < 0.1 sec Powering Off |
Operational Lifetime
|
> 3,000,000 (Switching Times)
|
||
How does the PDLC Film work?
With current switch, the PDLC film is vaporous due to the disordered arrangement of liquid
crystal molecules after turning off the power. On the contrary, when the power has opened,
neatly organized molecules will make smart film present transparency.
Details Images
Packing & Delivery
Standard export packing, with customized logo on shrinkage package, inner boxes and outer boxes
Company Profie
Founded in 1997, New Vision Group is the world's leading supplier of research, development and preparation of automotive solar film, commercial window film, Home Decoration Film, safety and security film. We continue to innovate around the needs of customers, each product has poured new horizons of cares to consumers, to create a comfortable and safe living space for consumers. At the same time, we are committed to providing competitive products and services for distributors, enterprises and partners, continuously improving customer experience and creating maximum value for customers.In the past 20 years, all employees of New Vision have made great efforts to participate in the global economic competition with an open attitude, and gradually developed into a global company with more than 50 countries and regions and thousands of distributors.
Exhibition
Certifications
FAQ
1.Q:What certificates do you have?
A: We have different certificates for company and our products.
1). Company Certificates: SGS, ISO, and other certificates for exporting, such as ICQ.
2). Products Certificates: CE, IWFA, Quality Management System Certificates.
2. Q: What is your payment term for order?
A: Our Payment term is T/T, L/C, western union, alipay or paypal.
3.Q: How about our delivery Lead Time?
A: 1),Small Quantity less than 10 rolls, we can delivery the goods within 5 working days. cause most of those films are available
directly from our stock.
2), Big Quantity, we can delivery the goods within 10-20 working days.
4.Q: Why do my windows look foggy after window tinting?
A: Window Tint is applied to glass that has been sprayed with a special liquid which allows the tint to be moved around and
positioned properly. Once in place, the tint is squeegeed extensively to remove as much of this moisture as possible but some is
always left behind. Over a period of between 5-7 days this will evaporate as the tint cures to the glass.
5.Q:What kind of cautions should be cared for after installation.
A:When tinting the window film, it usually turns blurry, cloudy, and displaying some different colors right after the
installation. However, these conditions will remain only 3 days in summer and a week in winter only after the water drying process
for tinting. Therefore, the window should be avoided turning up and down or avoided being touched. Do not directly scratch the
tinted window with sharp objects. The film surface has a hard coating, but nails or other sharp objects can make scratches.
Furthermore, do not put tape on tinted windows.
A: We have different certificates for company and our products.
1). Company Certificates: SGS, ISO, and other certificates for exporting, such as ICQ.
2). Products Certificates: CE, IWFA, Quality Management System Certificates.
2. Q: What is your payment term for order?
A: Our Payment term is T/T, L/C, western union, alipay or paypal.
3.Q: How about our delivery Lead Time?
A: 1),Small Quantity less than 10 rolls, we can delivery the goods within 5 working days. cause most of those films are available
directly from our stock.
2), Big Quantity, we can delivery the goods within 10-20 working days.
4.Q: Why do my windows look foggy after window tinting?
A: Window Tint is applied to glass that has been sprayed with a special liquid which allows the tint to be moved around and
positioned properly. Once in place, the tint is squeegeed extensively to remove as much of this moisture as possible but some is
always left behind. Over a period of between 5-7 days this will evaporate as the tint cures to the glass.
5.Q:What kind of cautions should be cared for after installation.
A:When tinting the window film, it usually turns blurry, cloudy, and displaying some different colors right after the
installation. However, these conditions will remain only 3 days in summer and a week in winter only after the water drying process
for tinting. Therefore, the window should be avoided turning up and down or avoided being touched. Do not directly scratch the
tinted window with sharp objects. The film surface has a hard coating, but nails or other sharp objects can make scratches.
Furthermore, do not put tape on tinted windows.
