Quick Details
-
Number of Cells:
-
customized
-
Panel Dimensions:
-
1220*555*25mm
-
Panel Efficiency:
-
21.3%
-
Keyword:
-
folding solar panels
-
Power Tolerance:
-
0~+3%
-
Max. Power Voltage Vmap:
-
20.16V
-
Max. Power Current lmp:
-
4.96A
-
Open Circuit Voltage Voc:
-
24.3V
-
Short Circuit Current lsc:
-
5.25A
-
Cell Type:
-
Mono,166*83cm
-
Weight:
-
4.8±0.1kg
-
Folded size:
-
610*555*45mm
Quick Details
-
Brand Name:
-
chuoji
-
Model Number:
-
customized
-
Place of Origin:
-
Jiangsu, China
-
Number of Cells:
-
customized
-
Panel Dimensions:
-
1220*555*25mm
-
Panel Efficiency:
-
21.3%
-
Keyword:
-
folding solar panels
-
Power Tolerance:
-
0~+3%
-
Max. Power Voltage Vmap:
-
20.16V
-
Max. Power Current lmp:
-
4.96A
-
Open Circuit Voltage Voc:
-
24.3V
-
Short Circuit Current lsc:
-
5.25A
-
Cell Type:
-
Mono,166*83cm
-
Weight:
-
4.8±0.1kg
-
Folded size:
-
610*555*45mm
Product Description
Specification
|
working voltage
|
Expand size
|
Closed size
|
working temperature
|
Waterproof level
|
|
2.3A/1.2A/1A
|
619 * 156 *3mm
|
160*156*24mm
|
-10C-60C
|
IP67
|
|
2.8A/1.7A/1.3A
|
825 * 156 * 3mm
|
160*156*27mm
|
|
|
|
3A/1.9A/1.5A/1.2A/1A
|
995 * 156 * 3mm
|
160*156*30mm
|
|
|
|
3A/3A/2.5A
|
825 * 280 * 3mm
|
196*280*24mm
|
|
|
|
3A/3A/3A/2.6A
|
1046 * 280 * 3mm
|
196*280*27mm
|
|
|
|
3A/3A/3A/2.6A/2.1A
|
1197*280*30mm
|
196*280*30mm
|
|
|
|
Max. Power Output Pmax
|
100W
|
200W
|
||
|
Power Tolerance
|
0~+3%
|
0~+3%
|
||
|
Max. Power Voltage Vmap
|
20.16V
|
20.16V
|
||
|
Max. Power Current lmp
|
4.96A
|
9.92A
|
||
|
Open Circuit Voltage Voc
|
24.3V
|
24.3V
|
||
|
Short Circuit Current lsc
|
5.25A
|
10.5A
|
||
|
Module Eficiency
|
21.3%
|
21.3%
|
||
|
*STC(Standard Test Condition): Irradiance 1000W/㎡,Cell Temperature 25℃,Air Mass 1.5.
|
|
|
||
|
MECHANICAL PARAMETERS
|
|
|
||
|
Cell Type
|
Mono,166*83cm
|
Mono,166*83cm
|
||
|
Cell Arrangement
|
36psc(3*6*2)
|
72psc(3*6*4)
|
||
|
Open size
|
1220*555*25mm
|
2390*535*25mm
|
||
|
Folded size
|
610*555*45mm
|
625*535*50mm
|
||
|
Weight
|
4.8±0.1kg
|
8.6±0.1kg
|
||
|
Output Cable
|
1500mm
|
1500mm
|
||
|
Output Connection
|
Anderson
|
Anderson
|
||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
