Quick Details
-
Brand Name:
-
Huatuo
-
Model Number:
-
SW-E-49-LUX
-
Main frame:
-
H-section Q355B
-
Purlin:
-
C/Z Galvanized Steel(Q235)
-
Roof and Wall:
-
Color Steel Sheet, Sandwich Panel
-
Surface treatment:
-
Painted or galvanized
-
Window:
-
Aluminum Alloy Window/ PVC Window/Skylight
-
Door:
-
Sliding Sandwich Panel Door/Rolling Metal Door/PVC Door
-
Steel structure:
-
Steel structure workshop
-
Application Fields:
-
Steel Structure Workshop Warehouse
-
Structure type:
-
Light Steel Structre
-
Life span:
-
50 Yeas
Quick Details
-
Grade:
-
Steel Structure
-
Tolerance:
-
±1%
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Huatuo
-
Model Number:
-
SW-E-49-LUX
-
Main frame:
-
H-section Q355B
-
Purlin:
-
C/Z Galvanized Steel(Q235)
-
Roof and Wall:
-
Color Steel Sheet, Sandwich Panel
-
Surface treatment:
-
Painted or galvanized
-
Window:
-
Aluminum Alloy Window/ PVC Window/Skylight
-
Door:
-
Sliding Sandwich Panel Door/Rolling Metal Door/PVC Door
-
Steel structure:
-
Steel structure workshop
-
Application Fields:
-
Steel Structure Workshop Warehouse
-
Structure type:
-
Light Steel Structre
-
Life span:
-
50 Yeas
IPE 400 Steel Structure Price cold form steel structure Prefabricated Warehouse/Workshop/Aircraft Hangar/Office Construction
| ITEMS | SPECIFICATION | |
| Main Steel Frame | Colum | Q355 Welded H Section Steel |
| Beam | Q355 Welded H Section Steel | |
| Secondary Frame | Purlin | Q235 C or Z purlin |
| Knee brace | Q235 Angle Steel | |
| Tie Rod | Q235 Circular Steel Pipe | |
| Brace | Q235 Round Bar | |
| Vertical and Horizontal Support | Q235 Angle Steel, Round Bar or Steel Pipe | |
| Maintenance System | Roof System | Roof Panel (EPS/Glass Wool/Rock Wool/PU Sandwich Panel or Corrugated Steel Sheet) and Accessories |
| Wall System | Roof Panel (EPS/Glass Wool/Rock Wool/PU Sandwich Panel or Corrugated Steel Sheet) and Accessories | |
| Window System | Aluminum Alloy Window/PVC Window/Skylight | |
| Door System | Sliding Sandwich Panel Door/Rolling Metal Door/PVC Door | |
| Others | PVC Rainspout,Gutter etc | |
| Wind Resisitance Grace | 12 Grades | |
| Earthquake-resistance | 8 Grades | |
| Structure life span | Up to 50 years | |
| Temperature | Suitable temperature -50℃~+50℃ | |
| Certification | CE, SGS, ISO9001:2008, ISO 14001:2004 | |
| Finishing Options | Vast array of colors and textures available | |
| Paint Options | Alkyd painting, two primary painting, two finish painting(gray paint, red paint, white paint, epoxy zinc etc.) or Galvanized. | |
Some Of Materials
Characteristics
1. Different types and sizes according to customer’s demand: large or small, wide span, single span or multiple spans.
2. Low cost and maintenance advantages .
3.Fast construction and easy installation: time saving and labor saving, all the items are factory-made.
4.Reduced construction waste, long using lifespan: up to 50 years.
5. Nice appearance.
6. Others: environmental protection, stable structure, High quake-proof, water proof and fire proof, and energy conserving.
Customers Visit Our Factory
1.Common type of the industrial building?
Reply: Portal frame is the usual type in the industrial workshop and warehouse shed. Other types also could be designed and manufacturer as per clients’ request.
2.What’s the quality grade of the steel structure components?
Reply: Q355 is used for main steel structure, Q235 is used for secondary steel structure.
3.How about the delivery time?
Reply: Usually, about 25-30 days after the order confirmed, also depends on the fabrication quantity.
4.How about the derust grade?
Reply: Ball blasting Sa 2.5 on main steel structure, manual derust St2.0 on secondary steel structure.
5.What kind panel used for the roof and wall?
Reply: Color corrugated steel sheet and sandwich panel could be used. Sandwich panel performs well on the heat insulation, sound insulation. Common sandwich materials are EPS, rock wool, glass wool and PU.
6.How to install it?
Reply: We will furnish you the detailed construction drawing and the construction manual which could help you to erect and install the building step by step. We also could send the engineer to your local to help you if needed.
