Quick Details
-
Voltage:
-
380v
-
Power:
-
6KW
-
Dimension(L*W*H):
-
based on capacity
-
Weight:
-
basec on capacity
-
Name:
-
Automatic fish fillet machine fish fillet processing line
-
Function:
-
Fish Fillet Making Machine
-
Application:
-
fish fillet fish ball and so on
-
Material:
-
304 Stainless Steel
-
Capacity:
-
100-1000kgh
-
Related machine:
-
skining, head removing, battering and so on
-
MOQ:
-
1set
-
automatic:
-
yes
-
from A to Z:
-
yes
-
Certification:
-
CE
Quick Details
-
Production Capacity:
-
60%
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
TCA
-
Voltage:
-
380v
-
Power:
-
6KW
-
Dimension(L*W*H):
-
based on capacity
-
Weight:
-
basec on capacity
-
Name:
-
Automatic fish fillet machine fish fillet processing line
-
Function:
-
Fish Fillet Making Machine
-
Application:
-
fish fillet fish ball and so on
-
Material:
-
304 Stainless Steel
-
Capacity:
-
100-1000kgh
-
Related machine:
-
skining, head removing, battering and so on
-
MOQ:
-
1set
-
automatic:
-
yes
-
from A to Z:
-
yes
-
Certification:
-
CE
Product Description
This is a complete line for the fish processing: including the preparatory processing and deep processing.
1. Preparatory processing: fish bleeding, fish -head removing machine, gutting table, middle bone removing machine, fish skin removing machine, washing
2. Deep processing machine:
Battering machine, tempura battering machine, breading machine, fring machine and IQF
|
Model
|
QTJ-1000
|
|
Size
|
2000*8850*1150mm
|
|
Capacity
|
30-50 pcs/min
|
|
material
|
SUS304
|
|
Power
|
1.45kw/h
|
|
Introduction
|
This machine is used to remove the fish head automaticly and high efficiently
|
|
Name
|
Middle-bone remover
|
|
Model
|
QGJ-300
|
|
Size
|
3500*700*1000mm
|
|
Capacity
|
300-400kg/h
|
|
Material
|
SUS304
|
|
Introduction
|
This machine is used to remove the middle bone for fish high efficiently.
|
|
name
|
fish skin removing machine
|
|
model
|
QPJ-300
|
|
size
|
620*570*900mm
|
|
capacity
|
300-400kg/h
|
|
material
|
sus304
|
|
introduction
|
This machine is used to remove the fish skin high efficiently.
|
|
name
|
Battering machine
|
|
model
|
LJJ-400 or 600
|
|
size
|
1936*1035*1450mm
|
|
speed
|
3-15m/min adjustable
|
|
Power
|
2.6kw
|
|
introduction
|
This machine is used to coat one layer thin batter to do preparation for predusting machine.
|
|
name
|
Predusting machine
|
|
model
|
SFJ-400 or 600
|
|
size
|
2655*1035*2150mm
|
|
Power
|
3kw
|
|
Speed
|
3-15m/min adjustable
|
|
Introduction
|
This machine is used to coat one layer of starch power uniformly and high efficiently.
|
|
name
|
Tempura battering machine
|
|
model
|
NJJ-400 or 600
|
|
size
|
3100*1120*1400mm
|
|
power
|
2.5kw
|
|
speed
|
3-15m/min adjustable
|
|
introduction
|
This machine is used to coat one layer of the thick batter automaticly by the conveying belt go through bath.
|
|
name
|
Breading machine
|
|
model
|
SXJ-400 or 600
|
|
size
|
2900×1160×2280mm
|
|
power
|
4.2kw
|
|
speed
|
adjustable
|
|
introduction
|
coat one layer of breadcrumbs uniformly automaticly. At the end of the belt with the extra breadcrumbs removing system. And with the extra breadcrumbs recycle system to collect for using again. Well matched with the before machine.
|
|
name
|
frying machine
|
|
model
|
XDL-6500 or 8500
|
|
heating system
|
electricity or gas or lpg or diesel
|
|
frying time
|
1min adjustable
|
|
speed
|
adjustable
|
|
introduction
|
it is for frying the burger or fill fillet
|
|
name
|
IQF Tunnel Freezer
|
|
model
|
SDJ
|
|
freezing time
|
20-100min
|
|
freezing temperature
|
-35℃
|
|
material
|
sus304
|
|
introduction
|
it is for instant quick freezing for the fish products.
can be spiral freezer or tunnel freezer based on request
|
Packing&Shipping
wood package or fixed in the container
After Sales Service
Installing and teaching
After making delivery we will arange engineers for the site installing and teach the customer how to use the processing line
Company Introduction
Zhucheng Xinxudong Machinery Co.,Ltd covering an area of 93240 square meter, have 150 staffs, including which 10 people are senior designer and 15 after sale service technicians, now we manufacture and sale of various of frying machine, frozen french fries production line, potato chips production line, Chicken Nuggets/Burger Patty machine,IQF tunnel freezer, drying machine and other auxiliary equipment.We have experienced technical team, focus on quality and service, constantly study international advanced technology. Our machine have sold to Germany, UK, Italy, Russia, United States,Canada, Austrilia, Brazil, India, Indonesia, Algeria, Saudi Arabia, United Arab Emirates,etc. more than 60 countries.
