Quick Details
-
Voltage:
-
380V/50HZ/3PH, Or Customized
-
Dimension(L*W*H):
-
6690*2040*1590mm
-
Application:
-
Factory
-
Weight (KG):
-
3150 KG
-
Power (kW):
-
77kw
-
Max.Working Width(mm):
-
500mm
-
Max.Working Height(mm):
-
170mm
-
Marketing Type:
-
for large timber sawmill cutting
-
Core Components:
-
motor and bearings, etc...
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Certification:
-
CE/ISO9001
-
Optional:
-
Auxiliary racks for wood conveying
-
Feeding speed:
-
0-23m/min
-
Effective processing width:
-
≤500m
-
Processing length:
-
≥1500mm
-
Processing height:
-
20-170mm
-
Specification of saw blade:
-
300*70
-
Specification of spacer:
-
120*70
Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
SHENGONG
-
Usage:
-
Sawing Plank/Square Log
-
Voltage:
-
380V/50HZ/3PH, Or Customized
-
Dimension(L*W*H):
-
6690*2040*1590mm
-
Application:
-
Factory
-
Weight (KG):
-
3150 KG
-
Power (kW):
-
77kw
-
Max.Working Width(mm):
-
500mm
-
Max.Working Height(mm):
-
170mm
-
Marketing Type:
-
for large timber sawmill cutting
-
Core Components:
-
motor and bearings, etc...
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Certification:
-
CE/ISO9001
-
Optional:
-
Auxiliary racks for wood conveying
-
Feeding speed:
-
0-23m/min
-
Effective processing width:
-
≤500m
-
Processing length:
-
≥1500mm
-
Processing height:
-
20-170mm
-
Specification of saw blade:
-
300*70
-
Specification of spacer:
-
120*70
|
Serial NO. / Model
|
MJF142S-1750
|
MJF142S-2250
|
|
|
Machine total power
|
77KW
|
93KW
|
|
|
Voltage / Ferquency
|
3HP-380V, 50HZ
|
3HP-380V, 50HZ
|
|
|
Feeding speed
|
0-23m/min
|
0-14m/min
|
|
|
Processing width
|
≤500mm
|
≤500mm
|
|
|
Processing length
|
≥1500mm
|
≥1500mm
|
|
|
Processing height
|
20-170mm
|
40-220mm
|
|
|
Appearance size（L*W*H）
|
2850*2040*1650mm
|
3160*2100*1670mm
|
|
|
Product weight
|
3150KG
|
3600KG
|
|
|
Blade Size
|
Φ300*Φ70
|
Φ350*Φ70
|
|
|
Spacer Size
|
Φ120*Φ70
|
Φ120*Φ70
|
|
|
Extra Wood Conveyor
|
Standard,Can removable
|
|
|
Why Choose US!-Quality Ensures Our Future!
Q1： What is your advantages?
A1： We have 43 years of experience in manufacturing and R&D. Because we are a manufacturer, not a trading company, we are professional and humane. We will definitely provide quality = price, price = quality, and the matching price is acceptable to our customers We welcome you to negotiate with us and get a good satisfaction. , in addition we can also provide excellent pre and after sales service.
Q2: Can I negotiate the prices for the machine?
A2: Yes, we may consider great discounts for mass buying quantity, the more you buy, the lower our price will be. Please contact with our sales and get the catalogue and quotation for your request .
Q3: How many days do you need for delivery?
A3: Some of our machines have stock available,once you ordered and made payment, we will deliver it ASAP. If it has no stock, we may need around 30-45 days for new production. Of course the delivery time is determined by the order you purchase. We will try our best to produce faster if your schedule is urgent.
Q4： How can I choose the machine I need?
A4： Just let us know the size, thickness and required working area of your cutting material and we will suggest the most suitable machine and professional solution, plus we offer customized.
Q5： Can you give warranty of your products?
A5： Yes, we have 1 year warranty to our products,please contact us immediately once you have any problems on it,the warranty will start when we load the machine at the factory for the spare part which is broken cuased by the quality of part, after 1 year , the part is payable by the customer .
Q6: How to install and operate the machine?
A6: Most machines are fully assembled in our factory, so just open and remove the package and turn on the power. For some machines,the main parts are already assembled and you may need to install some easy-to-install parts. If you have any questions,you cancontact us for more information on installation. If you need us to install and adjust, all costs are paid by your company,including air ticket from China to your company, hotel in your country, food in your country and Chinese translation in yourlanguage, etc. All costs occur in after-sales service and installation and adjustment.
Feel free to contact us on Alibaba, we will have great discounts.
