Quick Details
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
4200x1700x2500mm
-
Weight:
-
3500 KG
-
Product name:
-
vibrating screen
-
Application:
-
Gold mining
-
Capacity:
-
150 tons per hour
-
Recovery rate:
-
80-99%
-
Main Material:
-
High Hardness Carbon Steel
-
Sieve area:
-
6㎡
-
Mesh size:
-
4-50mm
-
After-sales Service Provided:
-
Field maintenance and repair service
Quick Details
-
Production Capacity:
-
100 tons per hour
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JINZUN
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
4200x1700x2500mm
-
Weight:
-
3500 KG
-
Product name:
-
vibrating screen
-
Application:
-
Gold mining
-
Capacity:
-
150 tons per hour
-
Recovery rate:
-
80-99%
-
Main Material:
-
High Hardness Carbon Steel
-
Sieve area:
-
6㎡
-
Mesh size:
-
4-50mm
-
After-sales Service Provided:
-
Field maintenance and repair service
Gold Panning Sluice Machine Hydraulic Vibrating Sluice Box For Gold Mining Plant
Product Description
Vibrating screen is a traditional screening equipment,is designed specifically for material stone screening in quarry, but also used for coal preparation, mineral processing, building materials, electricity and chemical departments for production classification. There are many types vibrating screen machinery,the most applicable in alluvial gold type is eccentric shaft type or vibrating motor type.
Specification
|
SPECIFICATION OF VIBRATING SCREEN
|
|
|
|
|||
|
Model
|
VS100
|
VS150
|
VS200
|
|||
|
Capacity
|
150 t/h
|
200 t/h
|
300t/h
|
|||
|
Motor Pover
|
15 kw
|
18.5 kw
|
22 kw
|
|||
|
Feeding Size
|
0-300mm
|
0-300mm
|
0-300mm
|
|||
|
Water Consumption
|
200 m³/h
|
250 m³/h
|
350 m³/h
|
|||
|
Screen Size
|
4200*1700 mm
|
5300*1900 mm
|
6000*2200 mm
|
|||
|
Meterial
|
Structure: Carbon steel , Screen: Polyurethane
|
|
|
|||
|
Weight
|
3.5 t
|
4.2 t
|
5 t
|
|||
Pictures And Details
1) Jinzun-VS series gold washing plant is designed according to your specific mining conditions and requirements.
2) A feeding system with a lime-soil funnel feeder, and the water spray pipe in the funnel sprays water to the soil.
3) Heavy-duty clay scrubber with internal high-pressure water spray pipes for separating hard clay. (If needed)
4) Double sieve sieve sieve with NSK bearings and high-pressure water spray pipes on both sides for cleaning, sieving and separation.
5) Double gold recovery system to ensure the highest gold recovery rate (up to 98%).
6) The water supply system is equipped with multiple sets of high-power submersible mud pumps, hoses, valves, etc.
7) The power system of Cummins diesel generator, including all batteries, cables and wires.
8) Multiple sets of heavy-duty mining tires with traction mechanism, with sufficient mobility and portability.
9) Gold refinery, which produces the final product of gold bars.
10) Easy to install, operate and maintain.
