Quick Details
-
Color:
-
256levels of each color(RGB)/16.7M colors
-
Panel Size:
-
320*160, 320*160
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
EASONCOLL-P2.5-32S
-
Pixel configuration:
-
1R1G1B
-
Package mode:
-
SMD2121
-
Pixel resolution:
-
128dots(W)*64dots(H)
-
Max Power consumpion:
-
25W
-
Module thickness:
-
17mm
-
Weight:
-
0.366KG
-
Drive type:
-
Constant drive
-
Scan mode:
-
1/32scan
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
EASONCOLL
-
Color:
-
256levels of each color(RGB)/16.7M colors
-
Panel Size:
-
320*160, 320*160
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
EASONCOLL-P2.5-32S
-
Pixel configuration:
-
1R1G1B
-
Package mode:
-
SMD2121
-
Pixel resolution:
-
128dots(W)*64dots(H)
-
Max Power consumpion:
-
25W
-
Module thickness:
-
17mm
-
Weight:
-
0.366KG
-
Drive type:
-
Constant drive
-
Scan mode:
-
1/32scan
Applications
Products Description
Product Features
(1) Pixel pitch 2.5 or below.High pixels density and perfect viewing experience.
(2) Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive. Information source can be camera, video, VCD, DVD, LD, TV and so on.
(3) Clear picture without flicker and distortion.
(4) Brightness, contrast, saturation can be adjust by itself and manual.
(5) Show everything with your PC does synchronously.
(6) Super correcting technology for distortion.
(7) One interface for sound signal and two for video signal at least.
(8) Connected and controlled by PC via Lan and remote control.
(9) Multiform language editions, such as English, French, Germany, Greek, Russian and so on
|
INDOOR P2.5 SMD 3IN1 TECHNICAL PARAMETERS
|
|
|
||
|
Size
|
Item
|
Parameter
|
||
|
|
Model Number
|
EASONCOLL-P2.5-32S
|
||
|
|
Module size
|
320mm*160mm
|
||
|
|
Pixel pitch
|
2.5mm
|
||
|
|
Pixels Density
|
160000 pitch/㎡
|
||
|
|
Pixel configuration
|
1R1G1B
|
||
|
|
Package mode
|
SMD2121
|
||
|
|
Pixel resolution
|
128dots(W)*64dots(H)
|
||
|
|
Max Power consumpion
|
25W
|
||
|
|
Module thickness
|
17mm
|
||
|
|
Weight
|
0.366KG
|
||
|
|
Drive type
|
Constant drive
|
||
|
|
Scan mode
|
1/32scan
|
||
|
|
Port type
|
HUB75
|
||
|
|
Brightness of white balance
|
≥800cd/㎡
|
||
|
Main technical
|
Driving device
|
Constant currentdriver
|
||
|
|
Refresh frequency
|
≥1920HZ
|
||
|
|
Grey scale/colors
|
256levels of each color(RGB)/16.7M colors
|
||
|
|
MTBF
|
≥10000hours
|
||
|
|
Power switch
|
Automatic switch
|
||
|
|
Best viewing distance
|
2.5M～10M
|
||
|
|
Best viewing angle
|
140°(W) 120°(H)
|
||
|
|
Temperature
|
storage:-20℃～+60℃
|
||
|
|
|
working:-10℃～+40℃
|
||
|
|
Opration humidity
|
10%-85%
|
||
|
Power
|
Working voltage
|
AC220V±10%
|
||
|
|
Average Power consumption
|
260W/㎡
|
||
|
|
Max.Power consumption
|
≤800W/㎡
|
||
|
|
Current
|
≤20mA(single LED)
|
||
|
Control system
|
CPU
|
With 4G or above graphics card
|
||
|
|
Operation system
|
WIN7 or above
|
||
|
|
Control method
|
Synchronization
|
||
