Quick Details
-
Brand Name:
-
DIEWU
-
Model Number:
-
TXE099-P
-
Place of Origin:
-
Guangdong, China
-
Warranty:
-
12 Months
-
Certification:
-
CE RoHS FCC
-
Support:
-
Vlan function
-
MAC Address Table:
-
8K
-
Switching Capacity:
-
16Gbps
-
Packet Forwarding Rate:
-
11.9Mpps
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
16Gbps
-
Brand Name:
-
DIEWU
-
Model Number:
-
TXE099-P
-
Place of Origin:
-
Guangdong, China
-
Warranty:
-
12 Months
-
Certification:
-
CE RoHS FCC
-
Support:
-
Vlan function
-
MAC Address Table:
-
8K
-
Switching Capacity:
-
16Gbps
-
Packet Forwarding Rate:
-
11.9Mpps
Advantages:
1. No need complex installation ,no need set up , easy to use ,it works after simple connection.
2.It can load 7 c omputers or other device at the same time .
3.Flexibale input power configuration design. 5V-20V input voltage acceptable.
4. Addistional Vlan design ,help users to avoid attacks from network storm
5. LED indicator shows status of power and network.
6. Wall mounting design for saving space.
|
Model number |
TXE099-P |
|
|
|
|
Chipset |
RTL8370N |
|
|
|
|
Port number |
8 port 10/100M/1000M Auto MDI-MDIX RJ45 |
|
|
|
|
Standard |
IEEE 802.3 , IEEE 802.3u , IEEE 802.3x , IEEE 802.3az |
|
|
|
|
Network media |
10Base-T,cat3 or above UTP,10Base-Tx,cat5 UTP |
|
|
|
|
Data rate |
10/100M/1000M |
|
|
|
|
Forwarding rate |
10 Mbps / 14,880 pps ,100 Mbps / 148,800 pps, 1000Mbps/1488000pps |
|
|
|
|
LED Indicator |
10/100M/1000Mbps(Link/Act),Power |
|
|
|
|
Dimension |
159*71*30mm |
|
|
|
|
Power Input |
DC5V/1000mA |
|
|
|
|
Power Consumption |
Max4.5W |
|
|
|
|
|
Operating Temperature: 0 ℃ -50 ℃ |
|
|
|
|
Environment |
Relative Humidity: 10%-90%(non-condensing) |
|
|
|
|
Storage Temperature: -40 ℃ -70 ℃ |
|
|
|
|
|
|
|
|
|
Relative Humidity: 5%-90%(non-condensing) |
|
|
