Quick Details
-
Machinery Test Report:
-
support
-
Marketing Type:
-
Hot Product 2020
-
Warranty of core components:
-
1
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MRJH
-
Key words:
-
Laminar Flow Hood
-
Keyword:
-
Clean Bench
-
Application:
-
dust-free workshop
-
Size:
-
1200*800*2050
-
Noise:
-
46-58
-
Cleanliness:
-
100 Class@ 0.3um
-
HEPA Filter:
-
99.995%@0.3um Efficiency
-
Hood type:
-
Straight
-
Air Velocity:
-
0.75m/s
-
Material:
-
Stainless Steel 304
Quick Details
-
Applicable Industries:
-
Electronics Factory
-
Weight (KG):
-
100
-
Video outgoing-inspection:
-
support
-
Machinery Test Report:
-
support
-
Marketing Type:
-
Hot Product 2020
-
Warranty of core components:
-
1
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MRJH
-
Key words:
-
Laminar Flow Hood
-
Keyword:
-
Clean Bench
-
Application:
-
dust-free workshop
-
Size:
-
1200*800*2050
-
Noise:
-
46-58
-
Cleanliness:
-
100 Class@ 0.3um
-
HEPA Filter:
-
99.995%@0.3um Efficiency
-
Hood type:
-
Straight
-
Air Velocity:
-
0.75m/s
-
Material:
-
Stainless Steel 304
Product Description
|
Shenzhen Meiri Purification Technology Co., Ltd
|
|
|
|
||||
|
CLEAN BENCH SPECIFICATION
|
|
|
|
||||
|
Name
|
Vetical Flow Clean Bench
|
Laminar Flow Clean Bench
|
Laminar Flow Clean Bench
|
||||
|
External Size
(mm) |
1200*600*1800
|
1000*825*1800
|
1200*900*1600
|
||||
|
Internal Size
(mm) |
1124*524*650
|
850*640*620
|
1100*700*720
|
||||
|
Cleanliness
|
Class100 @ 0.3um (99.99-99.99995%)
|
Class100 @ 0.3um (99.99-99.99995%)
|
ISO Grade 5 , FED 209E Class 100
|
||||
|
Noise
|
46-55DB±3DB (Static Testing below 1 M of HEPA )
|
50DB±5DB
|
58DB
|
||||
|
Power
|
220v 50hz/
|
220v 50hz/
|
220v 50hz/ 150~190W±5W
|
||||
|
Application
|
MEDICAL PHARMACY
FOOD INDUSTRY , LIVESTOCK, POWE PLANTS,HEALTHY CARE AND HOSPITAL , RESEARCH INSTITUTION , AEROSPACE TECHNOLOGY AUTO INDUSTRY |
|
|
||||
|
Air Speed (Adjustable)
|
0.45m/s
|
0.45m/s
|
0.45m/s~0.75m/s ±5% (three gears adjustable)
|
||||
|
Ilumination / Accessories
|
Energy Saving Lamp *2 ( Each on the back and front)
|
Clean Lamp*1 / Germicidal Lamp*1 : 18W/8W
|
Clean Lamp*1 / Germicidal Lamp*1 : 18W/8W
|
||||
|
CFU
|
≤0.5cfu/M/0.5H
|
≤0.5cfu/M/0.5H
|
≤0.5cfu/M/0.5H
|
||||
|
Applicable No. of People
|
1 Person
|
1 Person
|
1 person
|
||||
|
Warranty
|
3Years
|
3Years
|
3Years
|
||||
|
Material
|
Full SUS304
|
Outer Coated Cold-rolled Steel Plate / Inner SUS304
|
Outer Coated Cold-rolled Steel Plate / Inner SUS304
|
||||
Specifications:
1. Full frame is SUS 304.
2. The top is equipped with a stainless steel FFU size 1000*520*250mm.
3. Equipped with aluminum frame high-efficiency filter without partition (995*515*69mm); Efficiency: 100 class 00.13um 99.995% H13.
4. Wind speed: 0.45-0.75m/s ± 58% (three gear adjustable); Fan power supply: 220v 50Hz.
5. Noise: 46-55dB ± 3dB (static test 1m below HEPA)
6. Configured with 4 universal wheels (2 with brakes, 2 without)
7. There are 2 energy-saving lamps inside, each on the back and front.
8. Transparent tempered glass sealed on three sides.
9. The platform evenly punched 5mm; the spacing is 100x100.
